Atosa USA AEFF-50-1 Electric Fryer, Single Full Vat, 50 lb, Built-In Filtration, Programmable, 208V 3-Ph
Atosa USA AEFF-50-1 — Single Full Vat Electric Fryer, 50 lb
The AEFF-50-1 is a single full vat electric fryer battery: one 50 lb stainless steel tank at 17 kW in a 15-1/2" wide body. Fully programmable electronic controls set the cycle, built-in filtration with a pump is standard, and the tank comes with two baskets.
Key Features of the AEFF-50-1
A single-vat battery has to earn its floor space: full output on one tank, oil that stays usable, and controls a cook can set once and trust.
One 50 lb Full Vat
A single full 50 lb tank at 17 kW puts the whole electrical load behind one pot, so a busy fry item recovers fast between drops.
Fully Programmable Electronic Controls
The cycle is programmed rather than timed by hand, so the same product comes out the same whoever is on the station.
Built-In Filtration with Pump
The filtration system and pump are part of the battery, so oil is cleaned in place at the end of service rather than moved to a separate filter machine.
Two Baskets with the Tank
Two fryer baskets come with the tank, so half batches and full batches can both be run without buying anything extra.
17 kW on 208V Three Phase
The vat draws 17 kW at 48 A per wire on a minimum 6/4 AWG supply — the same service the larger batteries use per tank.
Two Casters, Two Legs
Single and double battery models ship with two casters at the rear and two legs at the front, so the fryer rolls forward for cleaning and sits level in service.
Electrical note: the AEFF-50-1 requires 208V three phase with a minimum wire size of 6/4 AWG and 48 A per wire, at 17 kW. Confirm the service at the install site before ordering.
Ideal Applications
One full vat in a 15-1/2" body is the fryer for a kitchen with a single fry item, or a second pot alongside an existing battery.
AEFF-50-1 Specifications
| Model | AEFF-50-1 |
|---|---|
| Brand | Atosa USA |
| Type | Single full vat electric fryer battery |
| Vat Configuration | 1 full vat |
| Oil Capacity | 50 lb |
| Baskets | 2 fryer baskets per tank |
| Tank Material | Stainless steel |
| Filtration | Built-in filtration system with pump |
| Controls | Fully programmable electronic controls |
| Power | 17 kW |
| Voltage | 208V, 3 phase |
| Amps Per Wire | 48 A |
| Minimum Wire Size | 6/4 AWG |
| Casters / Legs | 2 casters at the rear, 2 legs at the front |
| Exterior Dimensions (W x D x H) | 15-1/2" x 31" x 45-3/8" |
| Packing Dimensions (W x D x H) | 18-3/4" x 34-5/8" x 51-1/4" |
| Net Weight | 208 lb |
| Gross Weight | 284 lb |
| Filter Paper | FP-1324-5 (10-1/4" x 22", 100 sheets per box) |
| Related Models | AEFF-50-1B (same vat with auto lift), AEFF-50-1T (single split vat, 2 x 25 lb), AEFF-50-2 (double full vat), AEFF-50-3 (triple full vat) |
| Warranty | 1 year parts and labor |
Optional Accessories
Filter paper is the consumable the built-in filtration runs on; the rest are optional add-ons Atosa lists for the AEFF-50 series.
| FP-1324-5 | Filter paper, 10-1/4" x 22", 100 sheets per box |
|---|---|
| Fryer Mesh Screen | Optional |
| Vessel Covers | Optional |
| Side Splash | Optional |
Frequently Asked Questions
How is the AEFF-50-1 configured?
One full stainless steel vat holding 50 lb of oil, heated at 17 kW, in a 15-1/2" wide body.
What are the electrical requirements?
208V three phase, 48 A per wire, on a minimum 6/4 AWG supply, at 17 kW.
Does it include a filtration system?
Yes. A built-in filtration system with a pump is standard, and it runs on FP-1324-5 filter paper, 10-1/4" x 22", 100 sheets per box.
How many baskets come with the AEFF-50-1?
Two fryer baskets per tank.
Can the AEFF-50-1 be added to an existing fryer line?
Yes. Single and double batteries ship with two casters at the rear and two legs at the front, so the unit rolls into a line and levels beside the equipment already there.
How does the AEFF-50-1 compare to the other single batteries?
The AEFF-50-1 is one 50 lb full vat at 17 kW, 208 lb net. The AEFF-50-1B is the same vat with the auto lift system at 235 lb, the AEFF-50-1T splits the tank into two 25 lb wells at 8.5 kW each, and the AEFF-50-1TB is that split vat with auto lift.
