Atosa USA MBF8004GRL Reach-In Refrigerator, 1 Solid Left-Hinged Door, 21.4 cu. ft., Top Mount, R290
Atosa USA MBF8004GRL — One Door Reach-In Refrigerator, Left Hinged
The MBF8004GRL is a single section reach-in refrigerator with 21.4 cu. ft. behind one solid, left-hinged stainless steel door. The compressor sits on top, out of the floor dirt, and an electronic controller holds the cabinet at 35°F to 38°F on R290 refrigerant. Three shelves, an LED interior light, a door lock and 4" casters are all standard.
Key Features of the MBF8004GRL
A one door reach-in is the workhorse of a small back line: it has to hold temperature with the door opening all day, and it has to be cleanable. These are the parts that decide both.
One Solid, Left-Hinged Door
A single solid stainless door hinged on the left, with a recessed handle, a standard door lock and a magnetic gasket for a positive seal. It is self-closing with a stay open feature for loading.
35°F to 38°F on R290
A 1/7 HP top mount system running environmentally friendly R290 holds the cabinet in the 35°F to 38°F band Atosa recommends for food preservation, drawing 2.1 A.
Down Duct Refrigeration
Air is ducted down the cabinet rather than dumped in at one point, so the top shelf and the bottom shelf see the same temperature.
Electronic Control, LED Interior Light
The set point is read and adjusted on an electronic controller instead of guessed from a dial, and an LED interior light shows what is on the shelves without opening the door wide.
Three Epoxy Coated Shelves
Three epoxy coated shelves come pre-installed, so the cabinet is ready to load the day the crate is opened rather than waiting on a shelf order.
4" Casters, Pre-Installed
The cabinet ships on 4" casters, so a 220 lb unit rolls out for cleaning behind and underneath without an install step.
Placement note: leave the unit room to breathe and clean the condenser frequently to give it more fresh air — both are what Atosa asks for on this series. The MBF8004GRL runs on 115V, 60 Hz, single phase and plugs into a NEMA 5-15P outlet rated 15A / 125V.
Ideal Applications
A 28-3/4" wide, one door cabinet is the size that fits where a two door reach-in will not.
MBF8004GRL Specifications
| Model | MBF8004GRL |
|---|---|
| Brand | Atosa USA |
| Type | Top mount reach-in refrigerator, one section |
| Doors | 1, solid, left hinged; self-closing with stay open feature |
| Capacity | 21.4 cu. ft. |
| Shelves | 3, epoxy coated, pre-installed |
| Temperature Range | 35°F - 38°F |
| Refrigerant | R290 |
| Compressor | Top mount, 1/7 HP |
| Current | 2.1 A |
| Voltage | 115V / 60 Hz / 1 phase |
| Plug Type | NEMA 5-15P (15A / 125V) |
| Controller | Electronic temperature controller |
| Interior Light | LED |
| Door Handle | Recessed |
| Door Lock | Standard |
| Gaskets | Magnetic, standard for positive door seal |
| Airflow | Down duct refrigeration for even air distribution |
| Construction | Stainless steel exterior and interior |
| Casters | 4", pre-installed |
| Exterior Dimensions (W x D x H) | 28-3/4" x 31-3/4" x 81-3/8" |
| Net Weight | 220 lb |
| Gross Weight | 254 lb |
| Related Models | MBF8004GR is the same cabinet with the door hinged on the right; MBF15RSGR / MBF15RSGRL (13 cu ft, 1 door), MBF8005GR (2 doors, 43.2 cu ft), MBF8006GR (3 doors, 64.9 cu ft) |
| Warranty | 2 year parts and labor; 5 year compressor part |
Optional Accessories
Atosa lists extra shelving for this cabinet; each shelf ships with its own clips.
| Extra Shelf (W0402389) | Additional epoxy coated shelf for the MBF8004GR(L), includes 4 shelf clips per shelf |
|---|
Frequently Asked Questions
Does the MBF8004GRL have a glass door?
No. The MBF8004GRL has one solid stainless steel door. Atosa lists it as a top mount one door reach-in refrigerator with a stainless steel exterior and interior; there is no glass door version under this model number.
Which side is the door hinged on?
The left. The MBF8004GRL is the left-hinged version; the MBF8004GR is the same cabinet with the door hinged on the right. Both share the 21.4 cu. ft. capacity, the 28-3/4" x 31-3/4" x 81-3/8" cabinet and the 1/7 HP R290 system.
How much does the MBF8004GRL hold?
21.4 cu. ft. in one section, with three epoxy coated shelves pre-installed.
What temperature does it hold?
Between 35°F and 38°F, managed by an electronic temperature controller. That is the range Atosa recommends for the best food preservation results.
What are the electrical requirements?
115V, 60 Hz, single phase, drawing 2.1 A through a NEMA 5-15P plug rated 15A / 125V. The compressor is 1/7 HP running R290 refrigerant.
How does the MBF8004GRL compare to the rest of the MBF top mount line?
The MBF15RSGR and MBF15RSGRL are 13 cu ft with 1 door and 3 shelves; the MBF8004GR and MBF8004GRL are 21.4 cu ft with 1 door and 3 shelves; the MBF8005GR is 43.2 cu ft with 2 doors and 6 shelves; the MBF8006GR is 64.9 cu ft with 3 doors and 9 shelves. All run R290 on 115V.
