Atosa USA PLUS-R2-GS-S-PT Pass-Thru Refrigerator, 2 Section, Front Glass / Rear Solid Doors, 46.3 cu. ft., R290
Atosa PLUS-R2-GS-S-PT Pass-Thru Refrigerator — 46.3 cu. ft., Glass Front / Solid Rear
The PLUS-R2-GS-S-PT is the two-section pass-thru in Atosa's PLUS line: 46.3 cubic feet behind two double-pane glass doors at the front and two solid doors at the back, in a 51-3/4"-wide cabinet. Built into the wall between kitchen and service, it lets the kitchen load from behind while the front of house pulls from a lit, visible case. Eight shelves, a top-mounted heavy-duty Cubigel compressor on R290, and full electronic control holding 35°F to 38°F.
Built for Two-Sided Service
Pass-Thru Door Layout
Two sections, each with a glass door out front and a solid door behind — stock goes in from the kitchen and comes out on the service side without anyone crossing the line.
Double Pane Glass Doors
The front doors are double-pane glass with LED interior lighting, so product shows clearly while the second pane limits heat gain and condensation.
Top-Mount Cubigel Compressor, R290
A heavy-duty Cubigel compressor mounted on top stays clear of floor dust and mop water, running environmentally friendly R290 refrigerant at 1/2 HP.
Down-Duct Air Flow
A down-duct air flow channel spreads cold air evenly top to bottom, so the shelf nearest the door holds the same temperature as the one at the back.
Self-Closing Doors and Locks
All doors self-close with an automatic stay-open feature for loading, seal on magnetic gaskets, and lock as standard.
Casters and Shelf Clips Pre-Installed
4" casters and shelf clips are installed at the factory, so the cabinet rolls into place and the eight shelves go where you need them.
Where It Works
Specifications
| Model | PLUS-R2-GS-S-PT |
|---|---|
| Type | Top mount pass-thru refrigerator, 2 section |
| Capacity | 46.3 cu. ft. |
| Doors | 4 — 2 front glass doors, 2 solid rear doors |
| Shelves | 8 epoxy shelves (4 per section), pre-installed shelf clips |
| Temperature Range | 35°F - 38°F, full electronic controller |
| Refrigerant | R290 |
| Compressor | Heavy duty Cubigel, top mounted, 1/2 HP |
| Electrical | 115 V / 60 Hz / 1 phase |
| Rated Current | 4.5 A |
| Plug | NEMA 5-15P |
| Casters | 4", pre-installed |
| Exterior Dimensions (W x D x H) | 51-3/4" x 33-7/8" x 82-7/8" |
| Net / Gross Weight | 518 lb / 586 lb |
| Construction | Stainless steel / black exterior, stainless steel interior |
| Lighting | LED interior |
| Certifications | ETL-Sanitation, cETLus |
| Related Models | PLUS-R1-GS-R-PT, PLUS-R1-GS-L-PT (23.7 cu ft), PLUS-F2B-GD-S-PT (front & rear glass) |
| Warranty | 3 years parts and labor; 5 years compressor parts |
3-Year Parts & Labor / 5-Year Compressor
Atosa USA covers the PLUS-R2-GS-S-PT with a 3 year parts and labor warranty and a 5 year compressor part warranty.
Frequently Asked Questions
How many doors does the PLUS-R2-GS-S-PT have?
Four — two double-pane glass doors on the front and two solid doors at the rear, across two sections.
How much does it hold?
46.3 cubic feet on eight shelves, in a 51-3/4" wide x 33-7/8" deep x 82-7/8" high cabinet.
What temperature does it maintain?
35°F to 38°F on a full electronic controller — the range Atosa recommends for food preservation.
What electrical connection does the PLUS-R2-GS-S-PT need?
115V, 60 Hz, single phase, 4.5 amps, on a NEMA 5-15P plug. The compressor is 1/2 HP running R290.
Does it come with door locks and casters?
Yes — door locks are standard, and 4" casters plus shelf clips are pre-installed.
Is a version with glass on both sides available?
Yes — the PLUS-F2B-GD-S-PT uses the same cabinet with glass doors front and rear.
| Warranty Option | 3-Year Parts & Labor with 5-year parts warranty on Compressor or 5-Year Parts & Labor with 5-year parts warranty on Compressor or 7-Year Extended Warranty (Atosa Spec Series) or 8-Year Extended Warranty (Atosa Spec Series) |
| Brand | Atosa USA |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | PLUS-R2-GS-S-PT |
| Brand | Atosa USA |
| Weight | 586.00 lbs |
| Dimensions (HxWxD) | 86.00 x 53.00 x 36.00 inches |
| Height | 86.00 |
| Width | 53.00 |
| Depth | 36.00 |
| Door Style | hinged / swing |
| Exterior Finish | stainless steel |
| Door Type | glass (display) |
| Depth (front - back) | 35" - 36" |
| Refrigeration | self-contained, top mounted |
| Interior Finish | all stainless steel interior |
| Size | 2 section |
| Compressor HP | 1/2 HP |
|
