Atosa USA YRM0600A-261 Modular Ice Machine, 600 lb/24 hr, Half Dice Cube, 30"W, Air Cooled, R290, ENERGY STAR
Atosa YRM0600A-261 Modular Ice Machine — 600 lb/24 hr, Half Dice Cube
The YRM0600A-261 is the 600 lb model in Atosa's 30" modular ice machine line: an air-cooled, self-contained head that makes up to 600 lb of half-dice cube ice per 24 hours and sits on the storage bin of your choice. At 25-3/4" tall it is the shortest of the 208-230V heads in the family, which helps when ceiling or shelf clearance above the bin is tight. Stainless exterior, screwless front panel, removable air filter, and a 3M water filter system included standard.
How It Runs
600 lb of Half Dice Ice a Day
Half dice cubes at 3/8" x 7/8" x 7/8" pack tightly in a glass and chill fast — the all-purpose size for beverage service, salad bars and display.
R290 Refrigerant
Environmentally friendly R290 runs this head, with very low global warming potential and efficient heat transfer for the energy ratings the machine carries.
Digital Control
Digital control of the harvest cycle keeps production consistent and makes diagnostics straightforward when a tech comes out.
Air Cooled, Removable Filter
The air-cooled condenser uses no water for cooling, and its air filter pulls out for cleaning — the maintenance step that most affects daily ice output.
Screwless Front Panel
The stainless front panel comes off without tools, so the evaporator area and filter are accessible for routine cleaning in minutes.
3M Water Filter Included
The 3M water filter system and cartridge ship with the machine and should be installed at start-up. Atosa recommends replacing the cartridge every 6 months, depending on water quality.
Where It Works
Specifications
| Model | YRM0600A-261 |
|---|---|
| Type | Modular cube-style ice machine head, air cooled, self-contained |
| Ice Production | 600 lb per 24 hours |
| Ice Type | 1/2 (half dice) cube, 3/8" x 7/8" x 7/8" |
| Condenser | Air cooled, removable air filter |
| Refrigerant | R290 |
| Electrical | 208-230 V / 60 Hz / 1 phase |
| Rated Current | 6.8 A |
| Power | 1500 W |
| Plug | NEMA 6-20P |
| Exterior Dimensions (W x D x H) | 30-3/4" x 24-1/4" x 25-3/4" |
| Net Weight | 170 lb |
| Control | Digital |
| Exterior | Stainless steel, screwless front panel |
| Included | 3M water filter system, inlet hose, drain hose, ice scoop |
| Optional Accessory | Bin thermostat kit, part #BYR0400217031 |
| Plumbing | Requires use of a drain |
| Certifications | NSF, ETL, ETL-Sanitation, cETLus, ENERGY STAR |
| Related Models | YRM0450A-161 (450 lb), YRM0800A-261 (800 lb), YRM1000A-261 (1000 lb) |
| Warranty | 2 years parts and labor; 5 years compressor and evaporator |
2-Year Parts & Labor / 5-Year Compressor & Evaporator
Atosa USA covers the YRM0600A-261 with a 2 year parts and labor warranty plus 5 years on the compressor and evaporator. Maintenance and cleaning are not covered under warranty.
Frequently Asked Questions
How much ice does the Atosa YRM0600A-261 make?
Up to 600 lb of half dice cube ice per 24 hours.
Does the YRM0600A-261 include a storage bin?
No. It is a modular ice-making head and needs a separate storage bin sized to your usage.
What size ice does it produce?
1/2 (half dice) cubes measuring 3/8" x 7/8" x 7/8".
What electrical connection does the YRM0600A-261 need?
208-230V, 60 Hz, single phase, 6.8 amps, 1500 W, on a NEMA 6-20P plug.
What comes in the box?
The 3M water filter system, an inlet hose, a drain hose and an ice scoop. A bin thermostat kit (BYR0400217031) is available separately.
What warranty covers the YRM0600A-261?
2 years parts and labor plus 5 years on the compressor and evaporator. Maintenance and cleaning are not covered.
| Warranty Option | 2-Year Parts & Labor with 5-year parts warranty on Compressor or 3-Year Parts & Labor with 5-year parts warranty on Compressor or 4-Year Parts & Labor with 5-year parts warranty on Compressor or 5-Year Parts & Labor with 5-year parts warranty on Compressor |
| Brand | Atosa USA |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | YRM0600A-261 |
| Brand | Atosa USA |
| Weight | 193.00 lbs |
| Dimensions (HxWxD) | 25.75 x 33.75 x 24.25 inches |
| Height | 25.75 |
| Width | 33.75 |
| Depth | 24.25 |
| Width (side - side) | 30 - 39" wide |
| Condenser Type | air-cooled |
| Ice Type | half size / half dice cubes |
| Production per 24 hr | 601 - 700 lb = 273 - 317 kg |
| Refrigeration | self-contained refrigeration |
| Energy Efficiency | ENERGY STAR® |
|
