Blue Air BLPT72-D4RM-HC 72" Sandwich & Salad Prep Table, Left Door + 4 Drawers
Blue Air BLPT72-D4RM-HC — 72" Prep Table, Door Left, Four Drawers Right
Blue Air Commercial Refrigeration builds the BLPT72-D4RM-HC as a three-section, 72-3/8" refrigerated sandwich and salad prep table with a single self-closing swing door on the left and four pan drawers filling the middle and right sections. The doored end holds one adjustable epoxy-coated wire shelf for case packs and full-size pans, while the drawers put portioned product at the two positions a cook actually stands. All of it sits under an 18-pan cold rail in a 20.2 cu. ft. cabinet held between 33 °F and 39 °F by a rear-mounted 1/4 HP R-290 system.
Key Features of the BLPT72-D4RM-HC
Where the door sits changes how a six-foot line runs, and on this model it sits at the far left — out of the working zone, holding the bulk stock.
Swing Door at the Left End
One self-closing door closes the left section, so the swing arc stays at the end of the cabinet instead of interrupting the middle of the line. It rides on a durable, easily replaced gasket and a Ni-Cr plated all-metal handle that Blue Air guarantees for the life of the unit.
One Adjustable Wire Shelf Behind It
The doored compartment carries a single epoxy-coated wire shelf with adjustable height, which is where case packs, full-size pans and anything too tall for a 6" drawer belongs. That is the storage a straight six-drawer base gives up.
Four Drawers Across Two Sections
The middle and right sections carry two drawers each, all four built around 6" deep food pans. Backup proteins and prepped components lift straight up at waist height, so nobody crouches into a cabinet mid-ticket.
18-Pan Rail, Pans Supplied
Eighteen 1/6 size, 4" deep pans ship with the table and drop into an enclosed forced-air section with an air guard on the rear wall to even out circulation across the full 72-3/8". An insulated pan cover with a stainless steel divider keeps spillage out of the drawers and shelf below.
R-290 Charge, HFC-Free Foam
The self-contained 1/4 HP system runs on R-290 hydrocarbon refrigerant, which causes no ozone depletion, and the cabinet is foamed with cyclopentane insulation containing no hydrofluorocarbons. An electrodeposition-coated evaporator holds its heat-transfer rate and resists corrosion over the life of the unit.
Self-Diagnostic Digital Control
A digital temperature control and monitor system shows cabinet temperature on a front display and runs automatic evaporator fan motor delay. A visual and audible open alarm sounds when the left door or any drawer is not fully closed, before the 33 °F to 39 °F band slips.
Reading the model code: the D4RM suffix means drawers in the Right and Middle sections with the door fixed on the left. The layout is set at the factory and cannot be flipped in the field, so confirm which end of your line the door needs to open toward before ordering — the mirrored arrangement is a different model.
Ideal Applications
The end-door layout suits lines where one operator works the center and right of the table and stock is pulled from the outside.
BLPT72-D4RM-HC Specifications
| Model | BLPT72-D4RM-HC |
|---|---|
| Type | Sandwich / salad prep table, three-section, left door + right and middle drawers |
| Refrigerated Capacity | 20.2 cu. ft. |
| Pan Capacity (Top) | (18) 1/6 size × 4" deep pans, included |
| Drawers | (4), accommodate 6" deep pans |
| Doors | (1) self-closing swing door, left section |
| Shelves | (1) adjustable epoxy-coated wire shelf |
| Temperature Range | 33 °F – 39 °F |
| Exterior Width | 72-3/8" (1839 mm) |
| Exterior Depth | 30-3/64" (763 mm), excl. 3" handle & rear spacers |
| Exterior Height | 37-19/32" (955 mm), excl. 5" casters |
| Cutting Board | 9-1/2" deep × 1/2" thick, side rail bracket included |
| Refrigeration System | Self-contained, rear-mounted, easy-sliding condensing unit |
| Refrigerant | R-290 hydrocarbon |
| Horsepower | 1/4 HP |
| Electrical | 115 V / 60 Hz / 1 phase, 5.3 amps |
| Plug / Cord | NEMA 5-15P on a 9.8 ft (3 m) flexible three-wire cord |
| Insulation | Cyclopentane, HFC-free |
| Construction | Stainless steel interior & exterior, galvanized steel back & bottom |
| Casters | (4) 4" swivel, front two braked |
| Net Weight | 348 lbs (158 kg) |
| Shipping Weight | 379 lbs (172 kg) |
| Certifications | cETLus, ETL-Sanitation, conforms to NSF/ANSI 7 |
Frequently Asked Questions
What does D4RM mean on the BLPT72-D4RM-HC?
D4 is the drawer count and RM identifies where they go: two drawers in the Right section and two in the Middle, leaving the left section as a doored compartment. Blue Air sets that arrangement at the factory, so the door cannot be moved to the other end after delivery.
How does this differ from the six-drawer BLPT72-D6-HC?
Both cabinets are 72-3/8" wide and rated at 20.2 cu. ft. with the same 18-pan rail. The D6 replaces every door with a drawer, while the BLPT72-D4RM-HC keeps a self-closing door and one adjustable wire shelf on the left for case packs and tall containers that will not fit a 6" drawer.
Do the pans come with the table, and what size do the drawers take?
Yes — eighteen 1/6 size, 4" deep pans are supplied along with the insulated cover and stainless steel divider. The four drawers are dimensioned for 6" deep pans, which are ordered separately.
What electrical supply does this prep table need?
It runs on 115 V / 60 Hz single-phase power and draws 5.3 amps, so no high-voltage or three-phase service is required. The unit arrives with a 9.8 ft (3 m) flexible three-wire cord terminating in a NEMA 5-15P plug.
How much room should I plan for around the cabinet?
Allow the full 72-3/8" of length, then add 3" behind the listed 30-3/64" depth for the door handle and rear spacers and 5" beneath the 37-19/32" height for the casters. Because the condensing unit slides out of the back for service, keep the rear reachable rather than sealing the unit into a run.
How is condensation controlled around the door and drawer frames?
An innovative hot gas frame heating system routes refrigerant heat through the cabinet frame instead of using an electric heater, which reduces condensation at the openings while adding no separate electrical load. It works alongside the rounded corner design that keeps the perimeter easy to wipe down.
