Blue Air BLUR72-D4RM-HC 72" Undercounter Refrigerator, Left Door with 4 Drawers
Blue Air BLUR72-D4RM-HC — 72" Undercounter Refrigerator, Door Left and Drawers Right
Where its sister model puts the door in the center, the Blue Air Commercial Refrigeration BLUR72-D4RM-HC moves the single self-closing swing door to the far left and groups all four drawers across the middle and right sections. The result is 20.2 cu. ft. of undercounter refrigeration on a 72-3/8" chassis with an uninterrupted four-drawer run, which suits a line that flows left to right and finishes at the pass. Cooling comes from a rear-mounted 1/4 HP self-contained system on R-290 refrigerant, holding 33 °F to 39 °F.
Key Features of the BLUR72-D4RM-HC
Everything about this configuration is aimed at keeping the drawer bank continuous instead of splitting it around a door.
An Unbroken Four-Drawer Run
Because the door sits at the far left, the middle and right sections carry all four drawers in one uninterrupted stretch. Each takes a 6" deep pan, so a cook working the right half of the station never has to reach past a door frame to change out product.
Left-Hand Door for Bulk Storage
The left section holds the self-closing swing door with two adjustable epoxy-coated wire shelves. Putting it at the end of the run keeps a swinging door out of the traffic lane and makes the cabinet a natural fit at the left edge of a cook line or against a wall return.
Even Cooling End to End
An air guard on the rear wall pushes circulation across the full 72-3/8" of cabinet so the left door compartment and the far right drawer sit in the same 33 °F to 39 °F band. The electrodeposition-coated evaporator holds its heat-transfer rate and resists corrosion over the life of the coil.
R-290 and Cyclopentane Insulation
The 1/4 HP condensing unit is charged with R-290 hydrocarbon refrigerant, which has no ozone depletion potential, and the cabinet walls are foamed with HFC-free cyclopentane. A hot gas frame heating circuit replaces an electric anti-sweat heater at the openings.
Self-Diagnostic Digital Control
The digital temperature control and monitor system displays cabinet temperature, runs manual defrost on command, and triggers a visual and audible alarm if any drawer or the door is left open. That makes HACCP logging on the BLUR72-D4RM-HC a matter of reading the display.
Plan the swing before you set it: the left-hand door needs clear arc at the end of the cabinet, and the listed 30" depth excludes 3" for the handle and rear spacers. The rear-mounted condensing unit slides out for service, so leave the back accessible.
Ideal Applications
The door-left, drawers-right layout works best at the head of a line rather than in the middle of one.
BLUR72-D4RM-HC Specifications
| Model | BLUR72-D4RM-HC |
|---|---|
| Type | Undercounter reach-in refrigerator, three-section |
| Refrigerated Capacity | 20.2 cu. ft. |
| Drawers | (4), middle and right sections, accommodate 6" deep pans |
| Doors | (1) self-closing swing door on the left |
| Shelves | (2) adjustable epoxy-coated wire shelves |
| Temperature Range | 33 °F – 39 °F |
| Exterior Width | 72-3/8" |
| Exterior Depth | 30" (762 mm), excl. 3" handle & rear spacers |
| Exterior Height | 30-29/32" (785 mm), excl. 5" casters |
| Refrigerant / System | R-290 hydrocarbon, self-contained rear-mounted, 1/4 HP |
| Electrical | 115 V / 60 Hz / 1 phase, 5.2 amps, NEMA 5-15P |
| Cord | 9.8 ft (3 m) flexible three-wire with molded plug |
| Construction | Stainless steel interior & exterior, galvanized steel back & bottom |
| Casters | (4) 4" swivel, front two braked |
| Net / Ship Weight | 304 lbs (138 kg) / 373 lbs (169 kg) |
| Certifications | cETLus, ETL-Sanitation, conforms to NSF/ANSI 7 |
Frequently Asked Questions
Which side is the door on for the BLUR72-D4RM-HC?
The single self-closing swing door is on the left-hand section as you face the unit, and the four drawers occupy the middle and right sections. If you need the door in the center instead, the BLUR72-D4RL-HC splits its drawers two per side around a middle door on the same 72-3/8" cabinet.
How deep a food pan will the drawers take?
Blue Air lists the BLUR drawer sections as accommodating 6" deep pans, so a standard 6" insert drops straight in and anything deeper will not clear the drawer opening. The drawer sections do not use shelving — the two adjustable epoxy-coated wire shelves supplied with the unit belong in the left door compartment.
How much clearance does the condensing unit need?
The compressor is rear-mounted on an easy-sliding tray, so the back of the BLUR72-D4RM-HC should stay reachable for service and free enough for airflow. Also remember the published 30" depth does not include the 3" taken up by the door handle and rear spacers.
Is this undercounter refrigerator NSF listed for food contact?
It carries ETL-Sanitation and conforms to NSF/ANSI 7, the standard covering commercial refrigerated food service equipment, alongside cETLus electrical listing for the US and Canada. The stainless interior and rounded corner design are part of what makes that sanitation listing possible.
What does the open-door alarm actually do?
If a drawer or the swing door is not fully closed, the control sounds an audible tone and shows a visual warning rather than silently letting the cabinet warm. On a 20.2 cu. ft. box full of prepped product that warning is the difference between a quick fix and a morning of waste.
