Manitowoc IYP0320A Indigo NXT 22" Ice Machine Head Half Dice Cube 320 lb Air Cooled 230V 50Hz R290 Bin Sold Separately
Manitowoc IYP0320A — Indigo NXT 22" Half Dice Ice Machine Head, 320 lb
The Manitowoc IYP0320A is the half-dice version of the 22"-wide Indigo NXT iP0320 head, producing up to 320 lbs. of half dice cubes per day in an air-cooled, self-contained cabinet only 21.5" tall. Half dice cubes pack tightly in cups and blend easily, making them a favorite for soft drinks and smoothies. The unit runs on R290 natural refrigerant and is wired for 230 V / 50 Hz international supplies. easyTouch controls, programmable production and 24-hour intelligent diagnostics keep it simple to own, and the swing-out door with removable food-zone parts speeds cleaning. This is the ice machine head only — the storage bin is ordered separately; Manitowoc pairs it with the D320 or D420 bin.
Head only, 50 Hz model: the IYP0320A is sold without a storage bin — order a 22" Manitowoc bin such as the D320 or D420 separately. This unit is wired for 230 V / 50 Hz / 1 phase and is not intended for standard 60 Hz North American circuits; confirm your electrical supply before ordering.
Key Features of the IYP0320A
The iP0320 brings the full Indigo NXT control and cleaning package to a compact 22" head, here tuned for half dice cubes.
Half Dice Cubes
3/8" x 1-1/8" x 7/8" cubes (5.7 g) fill cups densely, displace more beverage and blend smoothly for frozen drinks.
easyTouch Display
An icon-based touch screen with multiple languages, chosen in the start-up wizard, shows status, reminders and cleaning steps.
Programmable Ice Production
Schedule the machine off at set hours to save on fluctuating electrical rates, or program by daily volume and night-time operation.
R290 Natural Refrigerant
Propane-grade R290 has no ozone depletion and near-zero global warming potential while keeping high performance.
Easy-Clean Food Zone
A hinged front door swings out, and the water trough, distribution tube, curtain, probe and pump remove for cleaning; select parts use AlphaSan antimicrobial.
Diagnostics & Acoustic Sensing
24-hour preventative diagnostics plus an acoustical ice sensing probe with Active Sense keep harvests consistent in tough water conditions.
Ideal Applications
A compact 50 Hz half dice head for drink-focused operations that need around 300 lbs. of ice a day.
Compatible Bins & Accessories
Manitowoc lists these for the iP0320; each is sold separately.
IYP0320A Specifications
| Model | Manitowoc IYP0320A (Indigo NXT iP0320) |
|---|---|
| Type | Modular cube ice machine head, air cooled, self-contained |
| What's Included | Ice machine head only; storage bin sold separately |
| Ice Shape | Half dice, 3/8" x 1-1/8" x 7/8" (5.7 g cube) |
| Production (70° air / 50° water) | 320 lbs. (145 kg) per 24 hrs |
| Production (90° air / 70° water) | 238 lbs. (108 kg) per 24 hrs |
| Energy Use | 5.63 kWh per 100 lbs. of ice |
| Potable Water Use | 20 gal. (76 L) per 100 lbs. of ice |
| Dimensions (W x D x H) | 22" x 24.5" x 21.5" (55.88 x 62.23 x 54.6 cm) |
| Electrical | 230 V / 50 Hz / 1 phase |
| Min. Circuit Ampacity / Max. Fuse | 6.0 A / 15 A |
| Refrigerant | R290 |
| Heat Rejection | 3,800 BTU/hr average, 4,800 peak |
| Ambient Range | 40°F to 110°F (4.4°C to 43.3°C) |
| Water Temperature / Pressure | 40°F to 90°F; 20 to 80 psi |
| Installation Clearance | 12" top and sides, 5" back |
| Connections | 3/8" F.P.T. water inlet; 1/2" F.P.T. water drain |
| Shipping Weight | 147 lbs. (67 kg) |
Frequently Asked Questions
Does the Manitowoc IYP0320A include an ice bin?
No. The IYP0320A is the ice machine head only. Order a 22" Manitowoc bin such as the D320 (264 lbs.) or D420 (383 lbs.) separately.
Can I run the IYP0320A on a standard US 60 Hz outlet?
No. The IYP0320A is the 230 V / 50 Hz / 1 phase version of the iP0320, intended for 50-cycle electrical supplies outside North America.
How much ice does the IYP0320A make?
Up to 320 lbs. of half dice cubes per 24 hours at 70° air and 50° water, and 238 lbs. at 90° air and 70° water.
What is the difference between the IYP0320A and the IDP0320A?
They share the same 22" iP0320 cabinet and 50 Hz electrical. The IYP0320A makes half dice cubes; the IDP0320A makes larger 7/8" dice cubes.
What size are half dice cubes?
Each half dice cube measures 3/8" x 1-1/8" x 7/8" (0.95 x 2.86 x 2.22 cm) and weighs about 5.7 g.
How much clearance does the IYP0320A need?
Manitowoc specifies at least 12" on the top and sides and 5" at the back for proper air-cooled operation.
