Atosa USA AWR48SD Worktop Refrigerator, 2 Doors, 48-1/4"W, 12.22 cu. ft., Stainless Steel, R290, ENERGY STAR
Atosa USA AWR48SD — 48" Worktop Refrigerator, 2 Doors
The AWR48SD puts 12.22 cu. ft. of refrigerated storage under a reinforced stainless steel top with a foamed-in-place backsplash, in a 48-1/4" wide cabinet holding 35°F to 38°F. Two field reversible doors open onto four epoxy shelves, a 1/7+ HP R290 system runs under an electronic controller, and the cabinet is ENERGY STAR qualified.
Key Features of the AWR48SD
A worktop unit has to be a work surface and a refrigerator at the same time, which means the top has to survive prep and the cabinet has to hold temperature under it.
Reinforced Top with Backsplash
The top is reinforced stainless steel with a foamed-in-place backsplash, so it takes prep work directly and keeps splatter off the wall behind it.
Two Field Reversible Doors
Both doors reverse on site so the swings suit the aisle, and two sections let different product be kept behind separate doors.
35°F to 38°F on R290
An environmentally friendly R290 system on a 1/7+ HP compressor holds the cabinet in the 35°F to 38°F band Atosa recommends for food preservation.
Electronic Temperature Controller
The set point is read and adjusted directly on an electronic controller instead of being estimated from a dial, so drift is caught early.
Self-Closing Doors, Magnetic Gaskets
The doors self-close with a stay open feature for loading with both hands, and magnetic gaskets are standard for a positive seal.
Pre-Installed 5" Casters
It ships on 5" casters for a 38-7/8" overall height, so the top lands at standing work height and the unit still rolls out for cleaning.
Placement note: leave the unit room to breathe and clean the condenser frequently so it keeps drawing fresh air through the rear grate. Atosa recommends a refrigerator set point between 35°F and 38°F. The unit runs on 115V, 60 Hz, single phase and draws 3.4 A through a 15A / 125V outlet.
Ideal Applications
A 48" worktop is the run of counter that has to double as cold storage for the station standing at it.
AWR48SD Specifications
| Model | AWR48SD |
|---|---|
| Brand | Atosa USA |
| Type | Worktop refrigerator with backsplash |
| Doors | 2, field reversible, self-closing with stay open feature |
| Capacity | 12.22 cu. ft. |
| Shelves | 4, epoxy coated |
| Temperature Range | 35°F - 38°F |
| Refrigerant | R290 |
| Horsepower | 1/7+ HP |
| Voltage | 115V / 60 Hz / 1 phase |
| Current | 3.4 A |
| Outlet Rating | 15A / 125V |
| Controller | Electronic temperature controller |
| Gaskets | Magnetic, standard |
| Construction | Stainless steel exterior and interior with reinforced stainless steel top and foamed-in-place backsplash |
| Casters | 5", pre-installed |
| Exterior Dimensions (W x D x H) | 48-1/4" x 30" x 38-7/8" |
| Net Weight | 201 lb |
| Gross Weight | 278 lb |
| Certifications | ENERGY STAR qualified |
| Related Models | AWR27SD (1 door, 6.53 cu ft), AWR36SD (2 doors, 8.97 cu ft), AWR60SD (2 doors, 15.5 cu ft), AWR72SD (3 doors, 18.89 cu ft); AWF48SD is the matching freezer |
| Warranty | Extended warranty available up to 5 years |
Optional Accessories
Coverage can be extended beyond the standard term, and the same cabinet is built as a freezer.
| Extended Warranty | Available up to 5 years |
|---|---|
| AWF48SD | Same 48-1/4" worktop cabinet built as a freezer, -8°F to 0°F |
Frequently Asked Questions
How much does the AWR48SD hold?
12.22 cu. ft. across two sections, with four epoxy coated shelves.
What temperature does the AWR48SD hold?
Between 35°F and 38°F on an electronic temperature controller, the range Atosa recommends for food preservation.
Can food be prepared on top of the AWR48SD?
Yes. The top is reinforced stainless steel with a foamed-in-place backsplash, built as a work surface, and on its pre-installed 5" casters the unit stands 38-7/8" high. Both doors are field reversible and self-closing with magnetic gaskets.
Is the AWR48SD ENERGY STAR qualified?
Yes. The AWR48SD is ENERGY STAR qualified.
What are the electrical requirements?
115V, 60 Hz, single phase, drawing 3.4 A on a 15A / 125V outlet. The compressor is 1/7+ HP on R290 refrigerant.
How does the AWR48SD compare to the other AWR worktops?
The AWR48SD is 48-1/4" wide with 2 doors and 12.22 cu ft. The AWR27SD is 27-1/2" with 1 door and 6.53 cu ft, the AWR36SD is 36-3/8" with 2 doors and 8.97 cu ft, the AWR60SD is 60-1/4" with 2 doors and 15.5 cu ft, and the AWR72SD is 72-5/8" with 3 doors and 18.89 cu ft. All are 30" deep and 38-7/8" high.
| Warranty Option | 3-Year Parts & Labor with 5-year parts warranty on Compressor or 5-Year Parts & Labor with 5-year parts warranty on Compressor or 7-Year Extended Warranty (Atosa Spec Series) or 8-Year Extended Warranty (Atosa Spec Series) |
| Brand | Atosa USA |
-
