Atosa USA BYR0300 Ice Storage Bin, 300 lb Capacity, 22-1/2"W, Stainless Steel, Scoop & Bin Adapter Included
Atosa USA BYR0300 — 22" Ice Storage Bin, 300 lb
The BYR0300 is a 300 lb ice storage bin in a 22-1/2" wide stainless steel cabinet with a food-grade plastic liner. The door is foam insulated and built to resist condensation, the hinge is damped with an anti-pinch design, and the bin ships with an ice scoop and a bin adapter so an Atosa ice machine head mounts straight on top.
Key Features of the BYR0300
A storage bin is the part of an ice system nobody thinks about until the door sweats onto the floor or slams on a hand — so those are the parts worth looking at.
300 lb of Ice Storage
Three hundred pounds of storage gives a bar or dining room a buffer between harvest cycles, so the draw during a rush is not limited to what the head can make in that hour.
Stainless Exterior, Food-Grade Liner
A stainless steel exterior over a food-grade plastic liner: the outside takes the knocks of a service corridor and the inside wipes down for sanitation.
Insulated Foam Door, Anti-Condensation
The door is foamed for insulation and built to resist condensation, so ice melts more slowly inside and the outside does not drip onto the floor.
Damper Hinge, Anti-Pinch Design
A damper hinge lowers the door under control instead of dropping it, and the anti-pinch design keeps fingers clear when the door closes.
Ice Scoop Included
An ice scoop ships with the bin, so the installation is not held up waiting for a separate sanitation-compliant scoop to arrive.
Bin Adapter Standard
Atosa ice bins come standard with a bin adapter, so the ice machine head sits square on the bin without ordering a separate mounting kit.
Installation note: the BYR0300 stands 41-1/2" high on 6" legs before the ice machine head is added, so check the total stacked height against the ceiling and any overhead shelving. Atosa recommends a water filter on all of its ice machines.
Ideal Applications
A 300 lb bin at 22-1/2" wide is the storage size for an operation that needs a real buffer but cannot give up three feet of floor.
BYR0300 Specifications
| Model | BYR0300 |
|---|---|
| Brand | Atosa USA |
| Type | Ice storage bin |
| Storage Capacity | 300 lb |
| Exterior | Stainless steel |
| Liner | Food-grade plastic |
| Foaming Material | C5H10 |
| Door | Insulated foam, anti-condensation |
| Hinge | Damper hinge with anti-pinch design |
| Legs | 6" |
| Included | Ice scoop; bin adapter standard |
| Exterior Dimensions (W x D x H) | 22-1/2" x 32-1/4" x 41-1/2" |
| Net Weight | 88 lb |
| Related Models | BYR0400 (400 lb, 30-1/4" wide) |
| Warranty | 2 year parts and labor; 5 year compressor part |
Optional Accessories
Atosa pairs the bin with its modular ice machine heads and recommends a water filter on every installation.
| BYR0400 | 400 lb ice storage bin, 30-1/4" wide — the larger bin in the series |
|---|---|
| Bin Adapter | Standard with the bin |
| Ice Scoop | Standard with the bin |
| Water Filter | Recommended on all Atosa ice machines |
Frequently Asked Questions
How much ice does the BYR0300 hold?
Up to 300 lb, in a 22-1/2" wide cabinet.
Does the BYR0300 make ice?
No. It is a storage bin. An Atosa ice machine head mounts on top of it, and the bin adapter needed to do that is standard.
What comes with the bin?
An ice scoop and a bin adapter are both standard.
What is the bin made of?
A stainless steel exterior over a food-grade plastic liner, with C5H10 foam insulation and a foamed, anti-condensation door.
How tall is the BYR0300?
41-1/2" high on its 6" legs, 22-1/2" wide and 32-1/4" deep, before the ice machine head is added on top.
How does the BYR0300 compare to the BYR0400?
The BYR0300 holds 300 lb in a 22-1/2" wide cabinet at 88 lb net. The BYR0400 holds 400 lb in a 30-1/4" wide cabinet at 97 lb. Both are 32-1/4" deep and 41-1/2" high on 6" legs.
