Atosa USA CD-15-L-WS Coffee Dispenser, 1.5 Gal., with Stand and Level Indicator, Vacuum Insulated, Stainless Steel
Atosa USA CD-15-L-WS — 1.5 Gallon Coffee Dispenser with Level Indicator and Stand
The CD-15-L-WS is a 1.5 gallon vacuum insulated coffee dispenser with a built-in level indicator, supplied with its stand. Double-wall vacuum insulation holds the coffee at or above 180°F for up to four hours with no power and no heating element, and the level indicator shows how much is left without lifting the lid.
Key Features of the CD-15-L-WS
A vacuum dispenser is a thermos built for service: no cord, no burner, a level you can read from the counter, and a pour that does not drip between customers.
Built-In Level Indicator
A sight gauge on the body shows the remaining volume at a glance, so staff know when to brew again without opening the dispenser.
Double-Wall Vacuum Insulation
The vacuum wall holds the coffee at or above 180°F for up to four hours without power, so flavor is not cooked off on a warmer plate.
1.5 Gallon Stainless Interior
A 5.68 liter stainless interior retains heat and takes a full brew cycle from a CB3L brewer in one pass.
Brew-Through Lid
The lid lets the brewer discharge directly into the dispenser, so coffee is never transferred from a pot and never sits open to the air.
Drip-Free Dispensing Spout
The spout is built for precise pouring and closes clean, which keeps the counter and the stand dry through a self-serve shift.
Stand Included
This WS model ships with the L-Stand fitted, putting the spout at cup height over a 22-3/4" overall height.
Compatibility note: the CD-15 coffee dispensers are specified for the short coffee brewer models, CB3L011 and CB3L021. This L version has the built-in level indicator; the CD-15-NL and CD-15-NL-WS are the same 1.5 gallon dispenser without one.
Ideal Applications
A vacuum dispenser is what moves brewed coffee away from the brewer and out to where people pour it.
CD-15-L-WS Specifications
| Model | CD-15-L-WS |
|---|---|
| Brand | Atosa USA |
| Type | Vacuum insulated coffee dispenser with level indicator and stand |
| Capacity | 1.5 gal / 5.68 L |
| Insulation | Double-wall vacuum |
| Heat Retention | At or above 180°F for up to 4 hours |
| Level Indicator | Built-in |
| Stand | L-Stand, included |
| Lid | Brew-through, removable |
| Spout | Drip-free dispensing spout |
| Construction | Stainless steel interior |
| Compatible Brewers | CB3L011 and CB3L021 short coffee brewers |
| Exterior Dimensions (W x D x H) | 8-7/8" x 14-3/8" x 22-3/4" |
| Shipping Dimensions (W x D x H) | 11-1/2" x 15-5/8" x 25-1/4" |
| Net Weight | 9.02 lb |
| Gross Weight | 10.23 lb |
| Certifications | NSF certified |
| Related Models | CD-15-L (level indicator, no stand), CD-15-NL (no level indicator, no stand), CD-15-NL-WS (no level indicator, with stand) |
| Warranty | 1 year parts and labor |
Optional Accessories
The stand is already fitted on this model; the alternatives below cover the rest of the CD-15 range.
| L-Stand | Stand for the CD-15-L — supplied with this CD-15-L-WS |
|---|---|
| CD-15-L | Same dispenser and level indicator without the stand |
| CD-15-NL-WS | Same 1.5 gal dispenser and stand without a level indicator |
| Compatible Brewers | CB3L011 (short, single) and CB3L021 (short, twin) |
Frequently Asked Questions
How much coffee does the CD-15-L-WS hold?
1.5 gallons, which is 5.68 liters.
How long does it keep coffee hot?
Double-wall vacuum insulation holds the liquid at or above 180°F for up to four hours. It needs no power and has no heating element.
What does the level indicator do?
It is a built-in sight gauge showing the remaining volume, so staff can see when the dispenser is running low without opening the lid.
Is the stand included?
Yes. The WS suffix means with stand, so the L-Stand ships fitted for a 22-3/4" overall height.
Which brewers can brew directly into it?
The short Atosa brewers, CB3L011 and CB3L021. The brew-through lid lets the brewer discharge straight into the dispenser.
How does the CD-15-L-WS compare to the other CD-15 dispensers?
All four are 1.5 gallon vacuum insulated dispensers. The CD-15-L-WS has both the level indicator and the stand, the CD-15-L has the level indicator only, the CD-15-NL-WS has the stand only, and the CD-15-NL has neither.
