Atosa USA TD-5T-DT Tea Dispenser, 5 Gal., Tall with Drip Tray, Stainless Steel, No-Drip Spigot, NSF
Tea Dispenser
5 Gallon Tall Tea Dispenser with Drip Tray and No-Drip Spigot
The Atosa USA TD-5T-DT is the largest of the Atosa tea dispensers — 5 gallons of brewed tea in a stainless steel body, on a tall frame with an integrated drip tray. The tall build is what matters at the brewer: the T models clear both short and tall Atosa coffee brewers, so the same dispenser works under either machine. A removable lid makes refilling and cleaning straightforward, and the durable no-drip spigot keeps the service counter dry.
Built for Service
5 Gallon Capacity
18.93 liters of brewed tea in a single vessel — enough to carry a lunch rush or a banquet line without a refill run.
Drip Tray Included
The DT models carry an integrated drip tray under the spigot, so overpour goes into the tray instead of onto the counter or the customer's tray.
No-Drip Spigot
A durable no-drip spigot gives consistent dispensing and shuts cleanly — the difference between a tidy tea station and a sticky one.
Removable Lid
The lid lifts off completely for refilling and for cleaning, so the inside of the vessel is reachable rather than just rinseable.
Fits Short and Tall Brewers
TD-3T-DT and TD-5T-DT work with both short and tall Atosa coffee brewer models. The L models fit only the short brewers, CB3L011 and CB3L021.
NSF Certified
Stainless steel body, NSF certified for commercial food service, and easy to wipe down between batches.
The line covers four combinations: TD-3L-ND and TD-5L-ND are short models without a drip tray; TD-3T-DT and TD-5T-DT are tall models with one. Pick the capacity for volume and the height for the brewer you own.
Where It Works
Specifications
| Model | TD-5T-DT |
|---|---|
| Type | Tea dispenser, tall model with drip tray |
| Capacity | 5 gal / 18.93 L |
| Body | Stainless steel |
| Lid | Removable |
| Spigot | Durable no-drip |
| Drip Tray | Included |
| Brewer Compatibility | Short and tall Atosa coffee brewer models |
| Exterior Dimensions | 6-3/4"W × 20-1/4"D × 21-1/4"H (170 × 510 × 538 mm) |
| Package Dimensions | 7-1/8" × 21-1/2" × 22" (181 × 546 × 559 mm) |
| Net Weight | 8.55 lb / 3.88 kg |
| Gross Weight | 10.63 lb / 4.82 kg |
| Certification | NSF certified |
The TD-5T-DT is covered by a 1 year parts and labor warranty from Atosa USA.
Frequently Asked Questions
How much does the TD-5T-DT hold?
5 gallons, which is 18.93 liters.
Does it come with a drip tray?
Yes. The DT in the model name means it includes a drip tray. The ND models ship without one.
Which coffee brewers does it fit under?
TD-5T-DT is a tall model and works with both short and tall Atosa coffee brewer models. The short TD-3L-ND and TD-5L-ND fit only the short brewers, CB3L011 and CB3L021.
What is the dispenser made of?
A stainless steel body with a removable lid and a durable no-drip spigot.
What sizes does the tea dispenser line come in?
3 gallon (11.36 L) and 5 gallon (18.93 L) capacities, each available as a short model without drip tray or a tall model with one.
Is the TD-5T-DT NSF certified?
Yes, it is NSF certified.
| Brand | Atosa USA |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | TD-5T-DT |
| Brand | Atosa USA |
| Weight | 11.00 lbs |
| Dimensions (HxWxD) | 22.00 x 7.00 x 21.50 inches |
| Height | 22.00 |
| Width | 7.00 |
| Depth | 21.50 |
| Valve | one valve |
| Type | side-by-side |
| Base Finish | stainless steel |
| Capacity | 5 gal |
|
