Atosa USA YDS0350A-161 Hotel Ice Machine & Dispenser, 23"W, 350 lb/24 hr, 160 lb Bin, Air Cooled
Atosa USA YDS0350A-161 — 23" Hotel Ice Machine and Dispenser
A complete self-service ice station in a 23-inch footprint: the YDS0350A-161 makes 350 lb of cube ice a day, stores 160 lb in its integral bin, and hands it out through a single push chute — a guest presses an ice bucket against the lever and walks away. No open bin, no shared scoop, no hand reaching into the ice.
Key Features of the YDS0350A-161
A guest-facing ice machine has to be sanitary, quiet about its maintenance needs, and impossible to use wrong. These are the details that get it there.
Single Push Chute Dispensing
Ice comes out through a push chute rather than an open bin. Nobody reaches in, no scoop gets left in the ice, and the stored ice never sees a guest's hands — the whole reason a dispenser exists rather than a bin.
Machine and Bin in One
350 lb of daily production over a 160 lb integral bin, all in a self-contained 23" cabinet on 6" legs. There is no separate head and bin to size, match and stack.
3M Water Filter Included
Every Atosa ice machine ships with a 3M filter system and cartridge. Filtered water means clearer, harder cubes and far less scale on the evaporator; Atosa recommends replacing the cartridge about every 6 months depending on water quality.
Removable Air Filter, Accessible Switch
The air-cooled condenser draws through a filter that slides out for cleaning, and the power switch can be reached without removing a panel — so routine service does not need a tech or a screwdriver.
R290 Refrigerant, 1200 W
R290 has a global warming potential of 3 against the hundreds or thousands of legacy HFC blends. The machine uses 5.68 kWh per 100 lb of ice on a standard 115 V circuit at 11.6 amps.
Large Overflow Drain Pan
A large drain pan catches overflow and drips at the dispensing chute, which is what keeps a guest-corridor installation from becoming a puddle and a slip hazard.
Plumbing and maintenance: this unit requires a drain. The water inlet is a 3/8" slip-style connector accepting 3/8" OD tubing; the water outlet and bin drain are 3/4" hose barbs for 3/4" rubber hose (hose clamp needed). Note that maintenance and cleaning are not covered under warranty — keep the condenser and 3M filter on a schedule.
Ideal Applications
A dispenser rather than a bin is what you want anywhere the public serves themselves.
YDS0350A-161 Specifications
| Model | YDS0350A-161 |
|---|---|
| Brand | Atosa USA |
| Type | Hotel ice machine and dispenser, self-contained, air cooled |
| Ice Production | Up to 350 lb per 24 hours |
| Bin Capacity | 160 lb |
| Ice Type | Cube ice |
| Dispensing | Single push chute |
| Exterior Dimensions (W x D x H) | 23" x 29-1/2" x 70-3/4" |
| Legs | 6" |
| Condenser | Air cooled with removable air filter |
| Refrigerant | R290 |
| Electrical | 115 V / 60 Hz / 1 Ph, NEMA 5-15 with 9 ft cord |
| Amps | 11.6 A |
| Power | 1200 W |
| Energy Use | 5.68 kWh per 100 lb of ice |
| Water Inlet | 3/8" slip-style connector, accepts 3/8" OD tubing |
| Water Outlet | 3/4" hose barb, accepts 3/4" rubber hose (clamp needed) |
| Bin Drain | 3/4" hose barb, accepts 3/4" rubber hose (clamp needed) |
| Water Filtration | 3M water filter system included |
| Construction | Stainless steel exterior with black trim |
| Net Weight | 270 lb |
| Certifications | NSF, cETLus, ETL Sanitation, ENERGY STAR |
| Warranty | 2 year parts and labor, 5 year compressor and evaporator |
Frequently Asked Questions
Do I need a separate ice bin?
No. Unlike a modular ice machine head, the YDS0350A-161 is a complete unit — it makes ice and stores 160 lb of it in an integral bin, then dispenses it through a push chute.
How does the dispenser work?
A single push chute: the user presses a container against the lever and ice drops into it. Nobody opens a bin or handles a scoop, which is why this style is specified for guest-facing and healthcare installations.
What plumbing does it need?
A water supply through a 3/8" slip-style inlet connector (accepts 3/8" OD tubing), and a drain — the water outlet and bin drain are both 3/4" hose barbs taking 3/4" rubber hose with a clamp. An inlet hose, drain hose and ice scoop are supplied.
What electrical service does it need?
A standard 115 V, 60 Hz, single-phase circuit. It draws 11.6 amps at 1200 watts and comes with a 9-foot cord and NEMA 5-15 plug.
How often should the water filter be changed?
Atosa recommends replacing the 3M cartridge about every 6 months, though the interval varies with local water quality. Every Atosa ice machine should be run with the included filter system installed.
How much space does it need?
The cabinet is 23" wide, 29-1/2" deep and 70-3/4" tall on its 6" legs. Leave it room to breathe rather than boxing it in — the air-cooled condenser needs airflow to hold rated production.
