Atosa USA YRS0350A-161 Ice Machine, 350 lb/24 hr, Half Cube Ice, 22-3/4"W, Air Cooled, R290, NSF
Atosa USA YRS0350A-161 — 22" Air Cooled Ice Machine, 350 lb per 24 Hours
The YRS0350A-161 is the entry point in Atosa's 22" ice machine line: up to 350 lb of half cube ice every 24 hours from a self-contained, air cooled head in a durable stainless steel cabinet. Digital control, a removable air filter and a screwless front panel keep service simple, and a 3M water filter system is included as standard.
Key Features of the YRS0350A-161
An ice machine is judged on what it produces and on how much work it takes to keep producing. These are the details that matter on both counts.
350 lb of Half Cube Ice a Day
Up to 350 lb per 24 hours in a 3/8" x 7/8" x 7/8" half cube — the size that packs a glass, chills fast and is easy to scoop.
Digital Control
Digital control manages the harvest cycle and gives clear status at the machine, so a problem shows itself before the bin runs empty.
Removable Air Filter, Screwless Panel
The air filter pulls out for cleaning and the front panel comes off without tools, so the two maintenance jobs that keep an ice machine alive actually get done.
3M Water Filter System Included
A 3M water filter system and cartridge ship with the machine. Filtration protects the evaporator and produces cleaner, clearer ice from day one.
R290 Refrigerant, Air Cooled
A self-contained air cooled system on environmentally friendly R290 refrigerant needs no remote condenser — just power, water and a drain.
NSF and ETL Listed
NSF and ETL listings mean the machine meets the sanitation and electrical standards an inspector looks for in a commercial installation.
Installation and maintenance: The machine requires the use of a drain, and should be left room to breathe with the condenser cleaned frequently. Install the included 3M water filter system and cartridge; Atosa recommends replacing the cartridge every 6 months, which may vary with water quality. Maintenance and cleaning are not covered under warranty.
Included Items and Accessories
The machine ships with the plumbing and handling pieces it needs, and two factory options adapt it to different bins.
| 3M water filter system | Included standard, with cartridge |
|---|---|
| Inlet hose, drain hose | Included |
| Ice scooper | Included |
| Bin thermostat kit | Optional, part BYR0400217031 — monitors bin temperature to detect a full bin and stop production automatically, preventing overflow, protecting the refrigeration system and improving energy efficiency |
| Bin adaptor | Optional, part BYR0400235001 — adapts the 22" head to a 30" bin |
Ideal Applications
350 lb a day on a 22" footprint suits operations with steady, moderate ice demand rather than a stadium's worth of it.
YRS0350A-161 Specifications
| Model | YRS0350A-161 |
|---|---|
| Type | Cube-style ice machine, self-contained, air cooled |
| Ice Type | 1/2 cube ice |
| Ice Dimension | 3/8" x 7/8" x 7/8" |
| Ice-Making Capacity | 350 lb per 24 hours |
| Exterior Dimensions (W x D x H) | 22-3/4" x 24-1/4" x 22" |
| Condenser | Air cooled, removable air filter |
| Refrigerant | R290 |
| Rated Power | 1,000 watts |
| Electrical | 115V / 60 Hz / 1-phase, 10.6 amps, NEMA 5-15P |
| Control | Digital |
| Exterior | Durable stainless steel, screwless front panel |
| Plumbing | Requires use of a drain |
| Included | 3M water filter system, inlet hose, drain hose, ice scooper |
| Certifications | NSF, ETL, cETLus, ETL Sanitation, ENERGY STAR |
| Net Weight | 88 lb |
| Brand | Atosa USA |
Frequently Asked Questions
How much ice does the YRS0350A-161 make?
Up to 350 lb of ice per 24 hours. The larger models in the same 22" line make up to 450 lb (YRS0450A-161) and up to 600 lb (YRS0600A-261).
What size is the ice?
Half cube ice measuring 3/8" x 7/8" x 7/8".
Does it come with a storage bin?
The YRS0350A-161 is the ice-making head. An ice storage bin is a separate purchase; an optional bin adaptor, part BYR0400235001, fits this 22" head to a 30" bin.
What does installation require?
A 115V / 60 Hz / 1-phase supply on a standard NEMA 5-15P receptacle at 10.6 amps, a water supply and a drain. The inlet hose, drain hose and 3M water filter system are included.
How often should the water filter cartridge be replaced?
Atosa recommends replacing the 3M cartridge every 6 months, though this may vary based on water quality. All Atosa ice machines should have the included 3M water filter system and cartridge installed.
Is there a way to stop production when the bin is full?
Yes. The optional bin thermostat kit, part BYR0400217031, monitors ice bin temperature to detect a full bin and automatically stops ice production, preventing overflow, protecting the refrigeration system and improving energy efficiency.
| Warranty Option | 2-Year Parts & Labor with 5-year parts warranty on Compressor or 3-Year Parts & Labor with 5-year parts warranty on Compressor or 4-Year Parts & Labor with 5-year parts warranty on Compressor or 5-Year Parts & Labor with 5-year parts warranty on Compressor |
| Brand | Atosa USA |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | YRS0350A-161 |
| Brand | Atosa USA |
| Weight | 139.00 lbs |
| Dimensions (HxWxD) | 22.00 x 22.75 x 24.25 inches |
| Height | 22.00 |
| Width | 22.75 |
| Depth | 24.25 |
| Condenser Type | air-cooled |
| Ice Type | half size / half dice cubes |
| Production per 24 hr | 401 - 500 lb = 183 - 227 kg |
| Refrigeration | self-contained refrigeration |
| Width (side - side) | 20 - 29" wide |
| Energy Efficiency | ENERGY STAR® |
|
