Blue Air BAPP67-D2L-HC 67" Refrigerated Pizza Prep Table, 2 Left Drawers & 1 Right Door
Blue Air BAPP67-D2L-HC — 67" Pizza Prep Table, Drawers Left and Door Right
The Blue Air Commercial Refrigeration BAPP67-D2L-HC is a 67" two-section refrigerated pizza prep table built around a split base: two drawers on the left, one self-closing door on the right. That mix gives a dough-and-topping station 20.2 cu. ft. of cold storage — drawer access for portioned product where the hands work, shelved door storage for cases and bulk on the far side. A side-mounted, front-breathing compressor keeps the cabinet serviceable in a narrow alcove, and the rail above carries nine 1/3 size pans under an insulated cover.
Key Features of the BAPP67-D2L-HC
Everything about this configuration is decided by which side the drawers land on — here they sit left, which suits a line that stretches and tops moving left to right.
Two Drawers on the Left Section
The left half of the base is given over to two drawers, so dough balls and pre-portioned proteins pull out at counter height instead of being buried behind a door. On a make line that runs left to right, that puts the most-touched product at the start of the motion.
One Self-Closing Door on the Right
The right section keeps a single hinged door with two epoxy-coated wire shelves that adjust on the cabinet uprights, which is where full cases and 6" bulk pans belong. The door is self-closing with a heavy-duty Ni-Cr plated all-metal handle and a replaceable gasket.
Nine-Pan Rail, 4" or 6" Deep
The top rail seats nine 1/3 size pans and accepts either standard 4" or 6" deep inserts, so you can run shallow cheese and sauce next to deep vegetable pans. An insulated pan cover with a stainless steel divider keeps spillage from reaching the storage cabinet beneath; pans are not included with the unit.
Forced-Air Drop-In Section
Fans push cold air into the enclosed drop-in area and an air guard on the rear wall evens out circulation across all 67", so the pan at the far end of the rail holds the same 33 °F to 39 °F as the one nearest the compressor.
Side-Mounted, Front-Breathing Compressor
The condensing unit sits at the side and breathes from the front, which lets the BAPP67-D2L-HC drop into a narrow bay and still be serviced without pulling the cabinet out of line. The easy-sliding condensing unit tray brings the components forward for cleaning.
R-290 Refrigerant and Coated Evaporator
A 3/8 HP self-contained system runs on R-290 hydrocarbon refrigerant, which has no ozone depletion potential, and the cabinet is filled with high-density foamed-in-place polyurethane insulation. The evaporator carries an epoxy coating that slows corrosion in a flour-and-moisture environment.
Measuring for your line: the listed 32-3/4" depth does not include 3-3/4" for the cutting board, and the listed 37" height does not include 5" for the casters. Allow the full 67" of length plus room for the door to swing on the right-hand section.
Ideal Applications
A 67" table with mixed drawer and door storage fits kitchens that need both fast-pick and case-depth cold storage in one footprint.
BAPP67-D2L-HC Specifications
| Model | BAPP67-D2L-HC |
|---|---|
| Type | Pizza prep table, two-section, drawer-and-door base |
| Refrigerated Capacity | 20.2 cu. ft. |
| Pan Capacity (Top) | (9) 1/3 size pans, 4" or 6" deep — pans not included |
| Drawers | (2), left section |
| Doors | (1), right section, self-closing |
| Shelves | (2) epoxy-coated adjustable wire shelves |
| Temperature Range | 33 °F – 39 °F |
| Exterior Width | 67" (1702 mm) |
| Exterior Depth | 32-3/4" (831 mm), excl. 3-3/4" cutting board |
| Exterior Height | 37" (939 mm), excl. 5" casters |
| Cutting Board | 19" deep × 1/2" thick, side rail bracket included |
| Refrigeration System | Side-mounted, front-breathing, self-contained; easy-sliding condensing unit |
| Refrigerant | R-290 hydrocarbon |
| Horsepower | 3/8 HP |
| Electrical | 115 V / 60 Hz / 1 phase, 3.5 amps |
| Plug / Cord | NEMA 5-15P on a 9.8 ft (3 m) three-wire flexible cord |
| Insulation | High-density foamed-in-place polyurethane |
| Evaporator | Epoxy coated |
| Construction | Stainless steel interior and exterior, galvanized steel back and bottom |
| Casters | (4) 4" swivel, front two braked |
| Net Weight | 390 lbs (176 kg) |
| Shipping Weight | 419 lbs (190 kg) |
| Options | 2.5" casters, 6" adjustable legs, additional shelves |
| Certifications | cUL, UL, ETL-Sanitation, conforms to NSF/ANSI 7 |
Frequently Asked Questions
Which side are the drawers on with the BAPP67-D2L-HC?
The L in the model number means the two drawers sit in the left-hand section, with the single self-closing door on the right. Blue Air builds the mirror-image BAPP67-D2R-HC for lines that need the drawers on the right, so pick the version that matches the direction your crew works.
Are food pans included with this pizza prep table?
No. The BAPP67-D2L-HC rail is sized for nine 1/3 size pans and will take either standard 4" or 6" deep inserts, but the pans themselves are ordered separately. The insulated pan cover and its stainless steel divider are included.
How much cold storage is there under the rail?
The cabinet holds 20.2 cu. ft. across both sections. That splits between the two left drawers and the right door compartment, which comes with two epoxy-coated wire shelves you can reposition on the uprights as your case sizes change.
Can this unit be installed in a narrow space?
Yes. The compressor is side-mounted and front-breathing, so the BAPP67-D2L-HC does not need rear clearance for airflow and can be pushed back against a wall. The easy-sliding condensing unit also means routine service happens from the front without moving the cabinet out of the line.
What electrical supply does the BAPP67-D2L-HC require?
It runs on 115 V / 60 Hz single-phase power and draws just 3.5 amps from a 3/8 HP system, so a standard kitchen circuit is enough. The unit ships with a 9.8 ft (3 m) three-wire flexible cord terminating in a NEMA 5-15P plug.
How much clearance should I leave when measuring?
Plan for 67" of length, then add 3-3/4" behind the published 32-3/4" depth for the cutting board and 5" above the published 37" height for the casters. Leave swing room on the right for the door, since that section is hinged rather than drawered.
| Brand | Blue Air Commercial Refrigeration |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | BAPP67-D2L-HC |
| Brand | Blue Air Commercial Refrigeration |
| Weight | 397.00 lbs |
| Dimensions (HxWxD) | 42.00 x 67.00 x 36.50 inches |
| Height | 42.00 |
| Width | 67.00 |
| Depth | 36.50 |
| Access Type | doors & drawers |
| Exterior Finish | all stainless steel exterior |
| Width (side - side) | 61" - 72" wide |
| Refrigeration | self-contained, side mounted |
| Sections | 2 section |
| No of Doors | 1 door |
| No of Drawers | 2 drawers |
| Work Surface Finish | poly cutting board |
|
