Blue Air BLMT60-D2R-HC 60" Mega Top Sandwich & Salad Prep Table, 2 Drawers + 1 Door
Blue Air BLMT60-D2R-HC — 60" Mega Top Prep Table with Two Right-Hand Drawers
The Blue Air Commercial Refrigeration BLMT60-D2R-HC is a two-section, 60-3/8" mega top sandwich and salad prep table built for menus that need more toppings than a standard rail can carry. Its mega top holds 24 one-sixth size pans — all included — over a 16.7 cu. ft. cabinet that splits into two drawers on the right and one self-closing door on the left, so line cooks get drawer access where they reach most and shelved bulk storage where they need depth. A rear-mounted, self-contained system charged with R-290 hydrocarbon refrigerant holds 33 °F to 39 °F all shift.
Key Features of the BLMT60-D2R-HC
The mega top is what separates this unit from a standard prep table, and the split drawer-and-door base is what makes a 60" cabinet carry two different kinds of storage at once.
24-Pan Mega Top, Pans Included
The extended mega top carries twenty-four 1/6 size pans, roughly a third more topping positions than a conventional rail of this width, and the pans ship with the unit. An insulated pan cover with a stainless steel divider keeps spillage out of the cabinet below.
Two Drawers on the Right
The right section is fitted with two drawers that accept 6" deep pans, putting portioned proteins and backup toppings at waist height on the side a right-handed cook works from. Nothing swings into the aisle when a drawer opens.
Self-Closing Door and Two Wire Shelves
The left section keeps a full-height self-closing door over two epoxy-coated wire shelves with adjustable height, so cases, tubs and taller containers still have somewhere to go. The door closes itself from 90 degrees or less and rides on lifetime-guaranteed all-metal Ni-Cr plated handles.
R-290 Refrigeration, HFC-Free Cabinet
A 1/4 HP self-contained system runs on R-290 hydrocarbon refrigerant with no ozone depletion potential, drawing only 4.9 amps on a standard 115 V circuit. The cabinet is foamed with cyclopentane insulation that contains no hydrofluorocarbons.
Digital Monitoring with Open Alarm
A self-diagnostic digital temperature control and monitor system displays cabinet temperature up front and handles automatic evaporator fan motor delay. A visual and audible alarm sounds when the door is not fully closed, before an unlatched door turns into a spoilage claim.
Measuring for your line: the listed 33-11/64" depth excludes 2-3/8" for the cutting board and 2-7/32" for the rear spacers, and the listed 39-11/64" height excludes 5" for the casters. Allow rear clearance as well — the easy-sliding condensing unit pulls out from the back for service.
Ideal Applications
A 24-pan top on a five-foot cabinet suits any station where the topping list is longer than the storage list.
BLMT60-D2R-HC Specifications
| Model | BLMT60-D2R-HC |
|---|---|
| Type | Mega top sandwich / salad prep table, two-section |
| Refrigerated Capacity | 16.7 cu. ft. |
| Pan Capacity (Mega Top) | (24) 1/6 size pans, included |
| Drawers | (2), right side, accommodate 6" deep pans |
| Doors | (1) self-closing, left side |
| Shelves | (2) epoxy-coated wire, adjustable height |
| Temperature Range | 33 °F – 39 °F |
| Exterior Width | 60-3/8" |
| Exterior Depth | 33-11/64" (843 mm), excl. 2-3/8" cutting board & 2-7/32" rear spacers |
| Exterior Height | 39-11/64" (995 mm), excl. 5" casters |
| Cutting Board | 9-1/2" deep × 1/2" thick, side rail bracket included |
| Refrigeration System | Self-contained, rear-mounted compressor, easy-sliding condensing unit |
| Refrigerant | R-290 hydrocarbon |
| Horsepower | 1/4 HP |
| Electrical | 115 V / 60 Hz / 1 phase, 4.9 amps |
| Plug / Cord | NEMA 5-15P on a 9.8 ft (3 m) three-wire flexible cord |
| Insulation | Cyclopentane, HFC-free |
| Evaporator | Electrodeposition coated |
| Construction | Stainless steel interior & exterior, galvanized steel back & bottom |
| Casters | (4) 4" swivel, front two braked |
| Net Weight | 295 lbs (134 kg) |
| Shipping Weight | 359 lbs (163 kg) |
| Certifications | cETLus, ETL-Sanitation, conforms to NSF/ANSI 7 |
Frequently Asked Questions
What makes the BLMT60-D2R-HC a mega top rather than a standard prep table?
A mega top extends the pan rail deeper across the cabinet, so this 60-3/8" unit carries twenty-four 1/6 size pans instead of the smaller count a conventional rail of the same width holds. Blue Air includes the pans with the unit, and an insulated cover with a stainless steel divider protects the storage area underneath.
Which side are the drawers on, and what pans do they take?
The two drawers sit in the right-hand section — that is what the D2R in the model number designates — and each accommodates 6" deep food pans. The left section keeps a full-height self-closing door with two adjustable epoxy-coated wire shelves for cases and taller containers.
What is the refrigerated capacity of the BLMT60-D2R-HC?
The cabinet is published at 16.7 cu. ft. across both sections. That is the capacity Blue Air and its dealers list for this configuration, and it covers the drawer section and the shelved door section beneath the mega top.
What electrical service does this prep table need?
It runs on standard 115 V / 60 Hz single-phase power and draws just 4.9 amps, so no dedicated high-voltage circuit is required. The unit ships with a 9.8 ft (3 m) three-wire flexible cord terminating in a molded NEMA 5-15P plug.
How much clearance should I plan around the cabinet?
Allow 60-3/8" of length, then add 2-3/8" for the cutting board and 2-7/32" for rear spacers beyond the listed 33-11/64" depth, plus 5" of height above the listed 39-11/64" for the casters. Keep the rear accessible as well, since the condensing unit slides out from the back for service.
| Brand | Blue Air Commercial Refrigeration |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | BLMT60-D2R-HC |
| Brand | Blue Air Commercial Refrigeration |
| Weight | 359.00 lbs |
| Dimensions (HxWxD) | 44.17 x 60.50 x 37.32 inches |
| Height | 44.17 |
| Width | 60.50 |
| Depth | 37.32 |
| Refrigeration | self-contained, rear mounted |
| Pan Capacity (Top) | 24 pan |
| Exterior Finish | all stainless steel exterior |
| Sections | 2 section |
| Width (side - side) | 60" - 63" wide |
| No of Doors | 1 door |
| Compressor Style | side / rear breathing |
| Access Type | doors & drawers |
| No of Drawers | 2 drawers |
|
