Blue Air BLUR60-D4-HC 60" Undercounter Refrigerator, 4 Drawers
Blue Air BLUR60-D4-HC — 60" Undercounter Refrigerator with Four Drawers
Step up from the 48-inch chassis and the BLUR60-D4-HC gives you a full five feet of refrigerated base — 60-3/8" of cabinet holding 16.7 cu. ft. behind four wide drawers instead of doors. Blue Air Commercial Refrigeration builds it in stainless inside and out, cools it with a rear-mounted R-290 system between 33 °F and 39 °F, and leaves the height at 30-29/32" so the unit still lives under a work counter.
Key Features of the BLUR60-D4-HC
The extra twelve inches over the 48-inch model go straight into pan capacity, not into wasted cabinet, and the rest of the build is aimed at long shifts.
Four Wide Drawers Across Two Sections
Each of the two sections carries a pair of drawers sized for 6" deep pans, giving 16.7 cu. ft. of reach without a single swinging door. Metal drawer handles are Ni-Cr plated and guaranteed for the life of the cabinet.
Five Feet Long, Still Undercounter Height
At 60-3/8" long, 30" deep and 30-29/32" high before casters, the BLUR60-D4-HC fills a five-foot bay while staying low enough to slide beneath a standard work surface with the 4" casters fitted.
Hot Gas Frame Heating
Rather than burning watts on an electric anti-sweat heater, Blue Air routes hot refrigerant gas through the cabinet frame. Condensation around the drawer openings drops without adding load to the 1/4 HP system.
Even 33 °F to 39 °F Across Five Feet
An air guard on the rear wall spreads forced air evenly, so a pan in the far left drawer holds the same temperature as one next to the compressor. The digital display and manual defrost sit on the front panel for daily checks.
Door-Open Alarm and Self-Diagnostics
The self-diagnostic control raises a visual and audible alarm the moment a drawer is not fully closed, which matters more on a 271 lb cabinet holding a full day's protein than on a small under-bar box.
Before you order: the 30" depth figure leaves out 3" for the handle and rear spacers, and the 30-29/32" height leaves out 5" for the casters. Blue Air also publishes the cabinet length as 60-1/2" on the cutsheet drawing versus the 60-3/8" listed spec — allow the larger number when you cut an opening.
Ideal Applications
Five feet of drawer storage suits stations that outgrew a 48-inch base but cannot give up counter height.
BLUR60-D4-HC Specifications
| Model | BLUR60-D4-HC |
|---|---|
| Type | Undercounter reach-in refrigerator, two-section, drawer base |
| Refrigerated Capacity | 16.7 cu. ft. |
| Drawers | (4), accommodate 6" deep pans |
| Shelves | None — drawer configuration |
| Temperature Range | 33 °F – 39 °F |
| Exterior Width | 60-3/8" |
| Exterior Depth | 30" (762 mm), excl. 3" handle & rear spacers |
| Exterior Height | 30-29/32" (785 mm), excl. 5" casters |
| Refrigeration System | Self-contained, rear-mounted, easy-sliding condensing unit |
| Refrigerant | R-290 hydrocarbon |
| Horsepower | 1/4 HP |
| Electrical | 115 V / 60 Hz / 1 phase, 5.0 amps |
| Plug / Cord | NEMA 5-15P on a 9.8 ft (3 m) three-wire cord |
| Insulation | Cyclopentane, HFC-free |
| Casters | (4) 4" swivel, two braked |
| Net Weight | 271 lbs (123 kg) |
| Shipping Weight | 328 lbs (149 kg) |
| Certifications | cETLus, ETL-Sanitation, conforms to NSF/ANSI 7 |
Frequently Asked Questions
How much more does the BLUR60-D4-HC hold than the 48" model?
The 60-3/8" cabinet is rated at 16.7 cu. ft. against 13.1 cu. ft. for the 48-inch BLUR48-D4-HC — about 3.6 cu. ft. more in the same drawer layout. Both use four drawers, so the gain shows up as wider pans per drawer rather than more compartments.
What size pans do the drawers on this Blue Air undercounter refrigerator take?
Every drawer is built to accommodate 6" deep food pans, the same depth used on Blue Air prep-table rails. That lets a kitchen standardize on one pan depth and move product straight from this base to a prep top without re-panning.
Does the BLUR60-D4-HC come with shelves?
No. This is a pure drawer base, so the cutsheet lists shelves as not applicable. If you need shelved storage at this width, look at the door-configured BLUR60 models instead.
What power does the BLUR60-D4-HC require?
115 V, 60 Hz, single phase at 5.0 amps, driven by a 1/4 HP compressor. It arrives with a 9.8 ft (3 m) three-wire cord and molded NEMA 5-15P plug, so a standard receptacle within reach of the unit is all that is needed.
How heavy is this unit and how does it move?
Net weight is 271 lbs and shipping weight is 328 lbs. It rides on four 4-inch swivel casters with brakes on the front pair, so one person can reposition it for cleaning once the drawers are empty.
| Brand | Blue Air Commercial Refrigeration |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | BLUR60-D4-HC |
| Brand | Blue Air Commercial Refrigeration |
| Weight | 328.00 lbs |
| Dimensions (HxWxD) | 35.88 x 60.38 x 33.03 inches |
| Height | 35.88 |
| Width | 60.38 |
| Depth | 33.03 |
| Refrigeration | self-contained, rear mounted |
| Access Type | drawers |
| Door Type | solid |
| Exterior Finish | stainless steel exterior |
| Width | 60" - 71" |
| Compressor HP | 1/4 HP |
| Size | 2 section |
|
