Blue Air BLMT72-D2M-HC 72" Mega Top Prep Table with Center Drawers & 2 Doors
Blue Air BLMT72-D2M-HC — 72" Mega Top Prep Table with Drawers in the Middle
The Blue Air Commercial Refrigeration BLMT72-D2M-HC is the center-drawer member of the 72-3/8" three-section mega top family: two 6" pan drawers sit in the middle bay with a self-closing swing door at each end, so the drawers stay an equal reach from either operator on a two-person line. The extended top carries thirty 1/6 size pans, all included, over 20.2 cu. ft. of R-290 cooled storage held between 33 °F and 39 °F.
Key Features of the BLMT72-D2M-HC
Same 72" chassis and same thirty-pan top as its stablemates — what this configuration changes is where the drawers sit, and that changes how two cooks share the station.
Drawers in the Middle Bay
The M in D2M puts both drawers in the center section, so neither end of a six-foot line has to reach past the other for portioned product. Each drawer takes 6" deep food pans and pulls straight out rather than swinging into the aisle.
A Self-Closing Door at Each End
Left and right sections both get full-height self-closing swing doors over two adjustable epoxy-coated wire shelves, giving you bulk storage at both ends of the cabinet. The doors close themselves from 90 degrees or less on lifetime-guaranteed Ni-Cr plated metal handles.
Thirty-Pan Mega Top
Thirty 1/6 size pans ship with the unit and sit under an insulated cover fitted with a stainless steel divider, which keeps spillage from working down into the drawers and shelves. Fans and a rear-wall air guard hold the whole rail at 33 °F to 39 °F.
Digital Control with Door Alarm
A self-diagnostic digital temperature control and monitor system reads out cabinet temperature and manages automatic evaporator fan motor delay. A visual and audible alarm fires when either end door is left ajar, which matters more on a unit with two doors than one.
R-290 Refrigeration, 5.4 Amps
The 1/4 HP self-contained system is charged with R-290 hydrocarbon refrigerant — no ozone depletion potential — and draws 5.4 amps on a standard 115 V circuit. Cyclopentane insulation is HFC-free and the evaporator is electrodeposition coated.
Fitting it to the line: the listed 33-11/64" depth excludes 2-3/8" for the cutting board and 2-7/32" for rear spacers, and the listed 39-11/64" height excludes 5" for the casters. Leave the back reachable — the condensing unit slides out from the rear for service.
Ideal Applications
Center drawers pay off wherever two people work the same table from opposite ends.
BLMT72-D2M-HC Specifications
| Model | BLMT72-D2M-HC |
|---|---|
| Type | Mega top sandwich / salad prep table, three-section |
| Refrigerated Capacity | 20.2 cu. ft. |
| Pan Capacity (Mega Top) | (30) 1/6 size pans, included |
| Drawers | (2), center section, accommodate 6" deep pans |
| Doors | (2) self-closing swing, left and right |
| Shelves | (2) adjustable epoxy-coated wire |
| Temperature Range | 33 °F – 39 °F |
| Exterior Width | 72-3/8" |
| Exterior Depth | 33-11/64" (843 mm), excl. 2-3/8" cutting board & 2-7/32" rear spacers |
| Exterior Height | 39-11/64" (995 mm), excl. 5" casters |
| Cutting Board | 9-1/2" deep × 1/2" thick, side rail bracket included |
| Refrigeration System | Self-contained, rear-mounted compressor |
| Refrigerant | R-290 hydrocarbon |
| Horsepower | 1/4 HP |
| Electrical | 115 V / 60 Hz / 1 phase, 5.4 amps |
| Plug | NEMA 5-15P cord set |
| Insulation | Cyclopentane, HFC-free |
| Construction | Stainless steel interior & exterior, galvanized steel back & bottom |
| Casters | (4) 4" swivel, front two braked |
| Net Weight | 340 lbs (154 kg) |
| Shipping Weight | 419 lbs (190 kg) |
| Certifications | cETLus, ETL-Sanitation, conforms to NSF/ANSI 7 |
Frequently Asked Questions
Where are the drawers on the BLMT72-D2M-HC?
Both drawers are in the center section — that is what the M in D2M stands for. The left and right sections each carry a self-closing swing door, so the drawers stay within equal reach of cooks working either end of the 72-3/8" cabinet.
How does this differ from the BLMT72-D2L-HC?
Mechanically the two are the same 72-3/8" three-section cabinet: 20.2 cu. ft., thirty top pans, 1/4 HP R-290 system, 5.4 amps. The difference is layout — D2M puts the two drawers in the middle with a door at each end, while D2L groups both drawers at the left with two doors to the right.
Are the food pans included with this prep table?
Yes. Blue Air supplies thirty 1/6 size pans for the mega top, and an insulated pan cover with a stainless steel divider comes fitted to keep spillage out of the storage area beneath. A 9-1/2" deep cutting board and its side rail bracket are included as well.
What does the BLMT72-D2M-HC weigh, and can it be moved?
It ships at 419 lbs and weighs 340 lbs net. Four 4" diameter swivel casters are standard with brakes on the front two, so a stocked station can still be rolled clear for cleaning or repositioned between services.
