Blue Air BLPT60-D4-HC 60" Refrigerated Sandwich & Salad Prep Table with 4 Drawers
Blue Air BLPT60-D4-HC — 60" Two-Section Prep Table with Four Drawers
Built on a two-section, 60-3/8" cabinet, the Blue Air Commercial Refrigeration BLPT60-D4-HC pairs a 16-pan cold rail with four drawers sized for 6" deep food pans. Underneath the drop-in top sits 16.7 cu. ft. of refrigerated storage, cooled by a rear-mounted self-contained system on R-290 hydrocarbon refrigerant that holds 33 °F to 39 °F. It is the mid-size unit in Blue Air's BLPT drawer-base range — a five-foot sandwich and salad station for kitchens where a 72" counter simply will not fit.
Key Features of the BLPT60-D4-HC
At 60-3/8" this is the prep table most operators land on when they need real drawer storage without giving up a full six feet of line.
Four Drawers, Two Sections
Two sections carry four drawers instead of doors, each deep enough for a 6" food pan. Cooks pull backup product up and out rather than crouching into a cabinet, and each drawer can be dedicated to one part of the menu.
16-Pan Drop-In Rail
Sixteen 1/6 size, 4" deep pans come with the unit and drop into an enclosed rail where fans force cold air around them. An insulated cover with a stainless steel divider blocks spillage from reaching the storage area beneath.
Steady 33 °F to 39 °F Holding
An air guard on the rear wall directs circulation through the cabinet so the far section holds the same temperature as the one next to the compressor, keeping the whole 60-3/8" cabinet inside the 33 °F to 39 °F band.
R-290 Refrigerant, HFC-Free Foam
The 1/4 HP self-contained system is charged with R-290, a natural hydrocarbon with no ozone depletion potential, and the walls are foamed with cyclopentane insulation that contains no hydrofluorocarbons.
Digital Monitoring with Open Alarm
A self-diagnostic digital temperature control and monitor system shows cabinet temperature on the display and runs automatic evaporator fan motor delay. A visual and audible alarm sounds if the unit is left open, protecting against overnight spoilage.
Stainless Build, Coated Evaporator
Stainless steel interior and exterior over a galvanized steel back and bottom, with an electrodeposition-coated evaporator that resists corrosion and maintains its heat-transfer rate over the life of the coil.
Before you measure the bay: the 30-3/64" depth on the spec sheet excludes 3" for the handle and rear spacers, and the 37-19/32" height excludes 5" for the casters. The condensing unit slides out from the rear, so leave that face reachable for service instead of pushing the cabinet flat to the wall.
Ideal Applications
A five-foot two-section drawer base fits the operations that need a full topping rail but cannot spare a six-foot run of wall.
BLPT60-D4-HC Specifications
| Model | BLPT60-D4-HC |
|---|---|
| Type | Sandwich / salad prep table, two-section, drawer base |
| Refrigerated Capacity | 16.7 cu. ft. |
| Pan Capacity (Top) | (16) 1/6 size × 4" deep pans, included |
| Drawers | (4), accommodate 6" deep pans |
| Shelves | None — drawer base configuration |
| Temperature Range | 33 °F – 39 °F |
| Exterior Width | 60-3/8" |
| Exterior Depth | 30-3/64" (763 mm), excl. 3" handle & rear spacers |
| Exterior Height | 37-19/32" (955 mm), excl. 5" casters |
| Cutting Board | 9-1/2" deep × 1/2" thick, side rail bracket included |
| Refrigeration System | Self-contained, rear-mounted, easy-sliding condensing unit |
| Refrigerant | R-290 hydrocarbon |
| Horsepower | 1/4 HP |
| Electrical | 115 V / 60 Hz / 1 phase, 5.0 amps |
| Plug / Cord | NEMA 5-15P on a 9.8 ft (3 m) three-wire molded-plug cord |
| Insulation | Cyclopentane, HFC-free |
| Construction | Stainless steel interior & exterior, galvanized steel back & bottom |
| Casters | (4) 4" swivel, front two braked |
| Net Weight | 315 lbs (143 kg) |
| Shipping Weight | 379 lbs (172 kg) |
| Certifications | cETLus, ETL-Sanitation, conforms to NSF/ANSI 7 |
Frequently Asked Questions
How does the BLPT60-D4-HC compare to the 72" BLPT72-D6-HC?
The BLPT60-D4-HC is the two-section version: 60-3/8" wide, 16.7 cu. ft., a 16-pan rail and four drawers. The BLPT72-D6-HC adds a third section for 72-3/8" of width, 20.2 cu. ft., 18 pans and six drawers. Refrigeration, controls and construction are otherwise the same, so the choice comes down to line length and how much backup storage you need.
Are the food pans included with this prep table?
Yes. Sixteen 1/6 size, 4" deep pans ship with the BLPT60-D4-HC, along with the insulated pan cover and its stainless steel divider. The drawers below take deeper 6" pans, which are available separately.
Can the cutting board be removed for cleaning?
The 9-1/2" deep, 1/2" thick cutting board mounts on a side rail bracket that comes with the unit, so it lifts off for washdown and goes back without tools. Remember that it overhangs the listed cabinet depth when you plan clearances.
What power does the BLPT60-D4-HC require?
A standard 115 V / 60 Hz single-phase outlet is all it needs, with a 5.0 amp draw. The 9.8 ft (3 m) flexible three-wire cord ends in a molded NEMA 5-15P plug, so no special receptacle or dedicated circuit is involved.
Is this unit certified for commercial food service?
It carries cETLus electrical listing and ETL-Sanitation, and conforms to NSF/ANSI 7 for refrigerated food service equipment. Those listings, combined with the digital temperature monitor, make routine HACCP logging straightforward for a health inspection.
| Brand | Blue Air Commercial Refrigeration |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | BLPT60-D4-HC |
| Brand | Blue Air Commercial Refrigeration |
| Weight | 379.00 lbs |
| Dimensions (HxWxD) | 42.50 x 60.38 x 33.03 inches |
| Height | 42.50 |
| Width | 60.38 |
| Depth | 33.03 |
| Width (side - side) | 60" - 62" wide |
| Refrigeration | self-contained, rear mounted |
| Sections | 2 section |
| Pan Capacity (Top) | 14 - 16 pan |
| Compressor Style | side / rear breathing |
| Exterior Finish | stainless steel & galvanized steel |
| Access Type | drawers |
| No of Drawers | 4 drawers |
|
