Airrex HSC-14R 1.2 Ton Portable Spot Cooler | 13,600 BTU Directed Cooling
Airrex HSC-14R — 13,600 BTU Portable Spot Cooler
The Airrex HSC-14R is a 1.2-ton portable spot cooler that delivers 13,600 BTU/h of directed cooling exactly where you need it. Built for industrial sites, repair shops, server rooms, and confined work areas, it runs on standard 115V power and rolls easily on four casters — a dependable solution for cooling hot spots without conditioning an entire building.
Why Choose the HSC-14R
Directed Spot Cooling
Two 5-inch front discharge nozzles aim 13,600 BTU/h of cold air precisely at people, equipment, or work zones.
R-454B Low-GWP Refrigerant
Runs on R-454B, a modern low-global-warming-potential refrigerant that meets current efficiency and environmental standards.
Digital Controls & Timer
Digital controls with high/low fan speed, a programmable timer, and auto-restart make daily operation simple and precise.
5-Gallon Tank, Auto Shut-Off
A 5-gallon condensate tank with automatic full-tank shut-off protects the unit; an optional condensate pump enables continuous drainage.
Washable Air Filters
Removable, washable aluminum and stainless-steel mesh filters on both sides; an optional HEPA filter kit is available.
Portable with Locking Casters
Four swivel casters (two locking) let you roll the HSC-14R into place and lock it securely wherever cooling is needed.
Safety Devices for Dependable Operation
The HSC-14R is engineered for long-term reliability in demanding environments.
A thermostat protector for the compressor works alongside high- and low-pressure switches, a 3-minute compressor delay timer, and fan motor protection. The automatic full-tank shut-off and tank position detector guard against overflow, while the ETL listing and LCDI recessed power cord confirm the unit meets recognized electrical safety standards.
Optional Accessories
An optional warm air duct kit includes ducting and a 2' x 2' ceiling flange for exhausting warm air, and an optional condensate pump plugs directly into the unit for continuous drainage in humid settings. A HEPA filter kit is also available and is shared across the (A)HSC-14R / 18R / 24R models.
Technical Specifications
| Model | Airrex HSC-14R |
|---|---|
| Cooling Capacity | 13,600 BTU/h (95°F / 40%) |
| Cooling Temp. Range (Nominal) | 61°F–86°F |
| Cooling Operating Range | 59°F–118°F |
| Dehumidification Operating Range | 55°F–115°F |
| Dehumidification Capacity | 14.4 gal/day nominal (26 gal/day max) |
| Refrigerant | R-454B |
| Outdoor Air Volume (High / Low) | 870 / 810 CFM |
| Sound Level w/ Exhaust Duct (High / Low) | 56 / 53 dB(A) |
| Power Consumption (Cooling) | 1.28 kW |
| Operating Current (Cooling) | 11.8 A |
| Cold Air Discharge | Two 5" diameter front nozzles |
| Warm Air Discharge | 12" diameter top flange |
| Condensate Tank | 5 Gallon (auto shut-off) |
| Power Requirement | 115V, 1 Phase, 60 Hz |
| Fuse Size / Plug | 15 A / NEMA 5-15 |
| Power Cord | 14 AWG 3-core, 10 ft, LCDI recessed |
| Dimensions (W x D x H) | 22" x 25" x 49" |
| Net Weight | 172 lbs |
| Casters | Four swivel (2 locking) |
| Certification | ETL Listed |
| Warranty | 1 Year (3 Years on Compressor) |
Frequently Asked Questions
What is the cooling capacity of the Airrex HSC-14R?
The HSC-14R delivers 13,600 BTU/h of cooling, rated at 95°F and 40% relative humidity. It is a 1.2-ton portable spot cooler built for directed cooling.
What power supply does the HSC-14R require?
It runs on standard 115V single-phase, 60 Hz power with a 15-amp fuse and a NEMA 5-15 plug. The LCDI recessed power cord is 14 AWG, 3-core, and 10 feet long.
What refrigerant does the HSC-14R use?
It uses R-454B, a modern low-global-warming-potential refrigerant chosen to meet current environmental and efficiency standards.
How does the HSC-14R handle warm air and condensate?
Warm air exhausts through a 12-inch top flange, and an optional warm air duct kit with a ceiling flange is available. Condensate collects in a 5-gallon tank with automatic shut-off, and an optional condensate pump allows continuous drainage.
Where is the HSC-14R typically used?
It is suited to industrial sites, car and aircraft repair shops, gas stations, server and machine rooms, event venues, and other spaces that need targeted cooling rather than whole-room air conditioning.
What warranty comes with the HSC-14R?
The unit is backed by a 1-year warranty, with extended 3-year coverage on the compressor.
