Atosa USA AUR36GD Undercounter Refrigerator, 2 Glass Doors, 36-3/8"W, 8.6 cu. ft., Stainless Steel, R290
Atosa USA AUR36GD — 36" Glass Door Undercounter Refrigerator, 2 Doors
The AUR36GD is a two-door glass front undercounter refrigerator holding 8.6 cu. ft. in a 36-3/8" wide stainless cabinet at 35°F to 38°F. Glass doors let staff and guests see the stock without opening the cabinet, a 1/6 HP R290 system runs under an electronic controller, and the doors are self-closing with magnetic gaskets.
Key Features of the AUR36GD
A glass door cabinet is bought to be looked into, so what matters is that the view stays clear and the cold stays in while it is being looked at.
35°F to 38°F on R290
An environmentally friendly R290 system on a 1/6 HP compressor holds the cabinet in the 35°F to 38°F band Atosa recommends for food preservation.
Glass Doors, Self-Closing
Two glass doors show the stock without the cabinet being opened, and they self-close with a stay open feature so nothing is left ajar during a rush.
Magnetic Door Gaskets
Magnetic gaskets are standard for a positive seal and lift out for cleaning, which matters on a cabinet that is opened all through service.
Electronic Temperature Controller
The set point is read and adjusted directly on an electronic controller instead of being estimated from a dial, so drift is caught early.
Two Epoxy Coated Shelves
Two shelves come pre-installed, sized so product sits square to the glass and reads clearly from the front of the counter.
Drawer Cartridges Available
Field installable drawer cartridges are an Atosa option, so the same cabinet can be converted to drawer storage for a pan-based station.
Placement note: leave the unit room to breathe and clean the condenser frequently so it keeps drawing fresh air. Atosa recommends a set point between 35°F and 38°F. The refrigerator plugs into a standard NEMA 5-15P outlet at 115V, 15A and draws 2.3 A.
Ideal Applications
A glass door undercounter belongs where the product is part of the display, or where staff need to check stock at a glance.
AUR36GD Specifications
| Model | AUR36GD |
|---|---|
| Brand | Atosa USA |
| Type | Glass door undercounter refrigerator |
| Doors | 2 glass, self-closing with stay open feature |
| Capacity | 8.6 cu. ft. |
| Shelves | 2, pre-installed |
| Temperature Range | 35°F - 38°F |
| Refrigerant | R290 |
| Horsepower | 1/6 HP |
| Voltage | 115V / 60 Hz / 1 phase |
| Current | 2.3 A |
| Plug Type | NEMA 5-15P (15A / 125V) |
| Controller | Electronic temperature controller |
| Gaskets | Magnetic, standard |
| Construction | Stainless steel exterior and interior |
| Casters | 2" heavy duty swivel plate, pre-installed |
| Exterior Dimensions (W x D x H) | 36-3/8" x 30" x 32-1/2" |
| Net Weight | 161 lb |
| Gross Weight | 198 lb |
| Related Models | AUR27GD (1 door, 6.4 cu ft), AUR48GD (2 doors, 11.8 cu ft), AUR60GD (2 doors, 15 cu ft), AUR72GD (3 doors, 18.2 cu ft) |
| Warranty | 3 year parts and labor; 5 year compressor part |
Optional Accessories
Drawer cartridges convert the cabinet to pan drawers in the field, and caster height changes the overall height of the unit.
| Drawer Cartridges | Field installable, in place of shelves |
|---|---|
| R06001000228 / R06001000229 | 1.2" swivel plate casters (with / without brake) — 31-1/4" overall height |
| R06001000063 | 1.5" swivel plate caster (with brake) — 31-7/8" overall height |
| B0604434 / B0604433 | 2" heavy duty swivel plate casters (with / without brake) — 32-3/8" overall height, standard |
| B0604421 / B0604413 | 4" swivel stem casters (with / without brake) — 34-3/8" overall height |
| B0604007 / B0604006 | 5" swivel stem casters (with / without brake) — 35-1/4" overall height |
| Extended Warranty | Available up to 5 years |
Frequently Asked Questions
How much does the AUR36GD hold?
8.6 cu. ft. behind two glass doors, with two shelves pre-installed.
What temperature does the AUR36GD hold?
Between 35°F and 38°F, the range Atosa recommends for food preservation, managed by an electronic temperature controller.
Do the glass doors close on their own?
Yes. Both doors are self-closing with a stay open feature, and they seal on magnetic gaskets.
What are the electrical requirements?
115V, 60 Hz, single phase, drawing 2.3 A through a NEMA 5-15P plug rated 15A / 125V. The compressor is 1/6 HP on R290 refrigerant.
Can the caster height be changed?
Yes. It ships on 2" heavy duty swivel plate casters at 32-3/8" overall height. Low profile 1.2" and 1.5" plate casters drop it to 31-1/4" or 31-7/8", and 4" or 5" swivel stem casters raise it to 34-3/8" or 35-1/4".
How does the AUR36GD compare to the other glass door AUR models?
The AUR27GD is 27-1/2" wide with 1 door and 6.4 cu ft, the AUR36GD is 36-3/8" with 2 doors and 8.6 cu ft, the AUR48GD is 48-1/4" with 2 doors and 11.8 cu ft, the AUR60GD is 60-1/4" with 2 doors and 15 cu ft, and the AUR72GD is 72-5/8" with 3 doors and 18.2 cu ft. All are 30" deep and 32-1/2" high.
