Atosa USA AWF48D4 Worktop Freezer, 4 Drawers, 48-1/4"W, 12.22 cu. ft., Stainless Steel, R290
Atosa USA AWF48D4 — 48" Work Top Freezer, 4 Drawers
The AWF48D4 is a work top freezer with four pan drawers: 12.22 cu. ft. of frozen storage under a reinforced stainless steel top with backsplash, holding -8°F to 0°F on an electronic controller. A 1/4+ HP system runs on R290 refrigerant, the unit ships with 1/6 size pans, and it rolls on pre-installed 5" swivel stem casters.
Key Features of the AWF48D4
Drawers instead of doors change how a frozen station works: the cook pulls one pan out at waist height instead of opening a cabinet and letting the cold fall out of it.
Four Pan Drawers
Four drawers split 12.22 cu. ft. into four working zones, so only the drawer in use is ever open and product stays sorted by station rather than by shelf.
Reinforced Top with Backsplash
A reinforced stainless steel top with a backsplash takes prep work directly on the surface and keeps splash off the wall the unit is pushed against.
-8°F to 0°F on R290
An environmentally friendly R290 system on a 1/4+ HP compressor holds the freezer range Atosa recommends for food preservation.
Electronic Temperature Controller
The set point is read and adjusted on an electronic controller rather than estimated from a dial position, so drift is caught before product is lost.
Ships with 1/6 Size Pans
Each unit comes standard with 1/6 size pans. Optional configurations cover 1/1, 1/2, 1/3 and 1/4 pan layouts if the station runs larger inserts.
5" Swivel Stem Casters
Standard 5" swivel stem casters — B0604007 with brake and B0604006 without — put overall height at 38-7/8" and let the unit roll out for cleaning.
Placement note: leave the unit room to breathe and clean the condenser frequently so it keeps drawing fresh air. Atosa recommends a set point between -8°F and 0°F. The freezer plugs into a standard NEMA 5-15P outlet at 115V, 15A and draws 4.8 A.
Ideal Applications
A four-drawer work top freezer is for stations that work off frozen pans all shift and need the surface above them too.
AWF48D4 Specifications
| Model | AWF48D4 |
|---|---|
| Brand | Atosa USA |
| Type | Work top freezer with drawers and backsplash |
| Drawers | 4 |
| Capacity | 12.22 cu. ft. |
| Temperature | -8°F to 0°F recommended set point |
| Refrigerant | R290 |
| Horsepower | 1/4+ HP |
| Voltage | 115V / 60 Hz / 1 phase |
| Current | 4.8 A |
| Plug Type | NEMA 5-15P (15A / 125V) |
| Controller | Electronic temperature controller |
| Handles | Recessed |
| Gaskets | Magnetic drawer gaskets |
| Pans Included | 1/6 size pans |
| Top | Reinforced stainless steel with backsplash |
| Construction | Stainless steel exterior and interior |
| Casters | 5" swivel stem, pre-installed |
| Exterior Dimensions (W x D x H) | 48-1/4" x 30" x 38-7/8" |
| Net Weight | 201 lb |
| Gross Weight | 278 lb |
| Related Models | AWF27D2 (2 drawers, 6.53 cu ft), AWF36D2 (2 drawers, 8.97 cu ft), AWF60D4 (4 drawers, 15.5 cu ft) |
| Warranty | 3 year parts and labor; 5 year compressor part |
Optional Accessories
Caster height changes the overall height of the cabinet. Atosa lists the following options with and without brakes.
| R06001000228 / R06001000229 | 1.2" swivel plate casters (with / without brake) — 34-3/4" overall height |
|---|---|
| R06001000063 | 1.5" swivel plate caster (with brake) — 35-3/8" overall height |
| B0604434 / B0604433 | 2" swivel plate casters (with / without brake) — 36" overall height |
| B0604421 / B0604413 | 4" swivel stem casters (with / without brake) — 37-7/8" overall height |
| B0604007 / B0604006 | 5" swivel stem casters (with / without brake) — 38-7/8" overall height, standard |
| Extended Warranty | Available up to 5 years |
Frequently Asked Questions
How much does the AWF48D4 hold?
12.22 cu. ft. across four pan drawers, under a reinforced stainless top with backsplash.
What temperature does the AWF48D4 hold?
Atosa recommends setting it between -8°F and 0°F, managed by an electronic temperature controller.
What pans does it take?
It ships standard with 1/6 size pans. Optional configurations cover 1/1, 1/2, 1/3 and 1/4 pan layouts.
What are the electrical requirements?
115V, 60 Hz, single phase, drawing 4.8 A through a NEMA 5-15P plug rated 15A / 125V. The compressor is 1/4+ HP on R290 refrigerant.
Can the caster height be changed?
Yes. It ships on 5" swivel stem casters at 38-7/8" overall height. Lower options give 34-3/4" (1.2" plate), 35-3/8" (1.5" plate), 36" (2" plate) or 37-7/8" (4" stem).
How does the AWF48D4 compare to the other AWF drawer models?
The AWF27D2 is 27-1/2" wide with 2 drawers and 6.53 cu ft, the AWF36D2 is 36-3/8" with 2 drawers and 8.97 cu ft, the AWF48D4 is 48-1/4" with 4 drawers and 12.22 cu ft, and the AWF60D4 is 60-1/4" with 4 drawers and 15.5 cu ft. All are 30" deep and 38-7/8" high on 5" casters.
| Warranty Option | 3-Year Parts & Labor with 5-year parts warranty on Compressor or 5-Year Parts & Labor with 5-year parts warranty on Compressor or 7-Year Extended Warranty (Atosa Spec Series) or 8-Year Extended Warranty (Atosa Spec Series) |
| Brand | Atosa USA |
-
