Blue Air BDD69-3B-HC 69" Three Keg Draft Beer Cooler, 3 Faucets, Black Vinyl
Blue Air BDD69-3B-HC — 69" Three Keg Cooler with a Single and a Double Tower
The Blue Air Commercial Refrigeration BDD69-3B-HC is the black-vinyl member of the BDD direct draw family: a 69-3/8" cabinet carrying three 1/2 barrel kegs in 23 cu. ft. of refrigerated space, dispensed through two 3" diameter stainless steel insulated beer columns — one fitted with a single faucet, one with a double — for three handles in all. Where the stainless BDD models are built to be looked at, this one is finished in black vinyl coated steel over a stainless top, which is the cheaper, more forgiving surface when the cooler lives under a bar die and takes knocks from kegs and hand trucks. A 3/8 HP R-290 system keeps all three barrels in the 33 °F to 39 °F pouring band, and at just 37" tall and 27-1/8" deep the cabinet tucks into a shallower well than the smaller 23" BDD box does.
Key Features of the BDD69-3B-HC
Three kegs, three handles and a wipe-clean black cabinet — here is what actually does the work on this model.
Three Half Barrels, Three Handles, Two Towers
The 23 cu. ft. interior takes three 1/2 barrel kegs — roughly 46 gallons of beer on tap at once. Blue Air splits the pour across two 3" diameter stainless steel insulated beer columns: one carries a single faucet, the other a double, so you can group two related handles together and keep the third apart. The standard column on the BDD range is 12" of stainless steel, insulated down the shank so the beer standing in it does not warm between pours.
Black Vinyl Coated Steel Over a Stainless Top
The -B suffix is the finish: stainless steel top with black vinyl coated steel walls, over a galvanized steel interior with a stainless steel floor. Black vinyl hides scuffs from keg dollies far better than brushed stainless and costs less to buy, which is why it is the usual pick when the cooler sits behind a bar die and only the top surface is ever on show.
33 °F to 39 °F, Air Guard and Automatic Defrost
One 3/8 HP system holds the whole three-keg bank between 33 °F and 39 °F, the range where CO2 stays in solution and pours come out clear rather than foamy. An air guard on the rear wall directs circulation so the keg nearest the coil is not colder than the one at the far end, and defrost runs automatically — nobody has to break down the bank to clear ice off the evaporator.
R-290 Hydrocarbon Charge and Hot Gas Frame Heating
The BDD69-3B-HC runs on R-290, a hydrocarbon refrigerant with no ozone depletion potential that Blue Air rates as more energy efficient than the HFC charge it replaces. An epoxy coated evaporator resists the corrosion that comes with a wet bar environment, and a hot gas frame heating system keeps condensation off the door frames using reclaimed heat instead of an electric heater wire.
Side-Mounted, Front-Breathing, Slides Out for Service
The compressor sits at the side of the cabinet and breathes through the front, so the cooler can be dropped into a 69-3/8" opening with millwork tight to the back and both ends without choking the condenser. The condensing unit is on an easy-sliding base, which means a technician can pull it forward for a coil clean without emptying three kegs and dragging the box off the line.
37" Tall, 27-1/8" Deep, Two Locking Doors
At 37" high to the stainless top and 27-1/8" deep, this is a lower, shallower cabinet than the 23" single-keg BDD, which matters when it has to slide under a bar top. Two doors with black recessed handles, standard locks and easily replaced gaskets close over the three-keg bank, and each section carries two adjustable shelves with enough interior height to stack three tall boy cans when a keg is not on.
Measuring the bar opening: the 37" height is to the stainless steel top — add the 12" beer tower on top of that when you check faucet height and any overhead shelf. Unlike the 23" BDD chassis, neither casters nor legs are standard here: 6" legs and 4" casters are both listed as options, so specify one and allow for the extra height it adds. Depth is 27-1/8" and the cord is 9.8 ft long, which usually reaches a receptacle at either end of a 69" run.
Ideal Applications
Three taps on one compressor is the sweet spot for a bar that pours more than a house draft but does not need a full wall of handles.
BDD69-3B-HC Specifications
| Model | BDD69-3B-HC |
|---|---|
| Type | Direct draw draft beer cooler / keg cooler |
| Keg Capacity | (3) 1/2 barrels |
| Refrigerated Capacity | 23 cu. ft. |
| Dispensing | (2) 3" dia. stainless steel insulated beer columns — (1) single faucet and (1) double faucet |
| Beer Tower | 12" stainless steel (standard on BDD series) |
| Temperature Range | 33 °F – 39 °F |
| Doors | (2) locking, black recessed handles, replaceable gaskets |
| Shelves | (2) adjustable per section |
| Air Circulation | Air guard on rear wall |
| Defrost | Automatic |
| Lighting | Interior LED |
| Exterior Width | 69-3/8" |
| Exterior Depth | 27-1/8" (688 mm) |
| Exterior Height | 37" (940 mm), to stainless top |
| Refrigeration System | Self-contained, side mounted, front breathing, easy sliding condensing unit |
| Refrigerant | R-290 hydrocarbon |
| Insulation | High-density foamed-in-place polyurethane |
| Evaporator | Epoxy coated |
| Horsepower | 3/8 HP |
| Electrical | 115 V / 60 Hz / 1 phase, 3.5 amps |
| Plug | NEMA 5-15P, 9.8 ft (3 m) flexible three-wire cord with molded plug |
| Construction | Stainless steel top with black vinyl coated steel exterior; galvanized steel interior with stainless steel floor |
| Legs / Casters | 6" legs and 4" casters available as options |
| Net Weight | 240 lbs |
| Shipping Weight | 265 lbs |
| Certifications | UL, cUL, ETL-Sanitation, conforms to NSF/ANSI 7 |
Frequently Asked Questions
What is the tap configuration on the Blue Air BDD69-3B-HC?
Two 3" diameter stainless steel insulated beer columns are supplied: one carries a single faucet and the other carries a double faucet, giving three taps for the three 1/2 barrel kegs the cabinet holds. Splitting the handles across two towers rather than putting all three on one column lets you spread the pour stations along a 69" bar instead of crowding them at one point.
What does the -B in BDD69-3B-HC mean?
It designates the exterior finish. The -B unit has a stainless steel top over black vinyl coated steel walls, while the -S version of the same cabinet is stainless steel all round. Mechanically they are the same cooler — same 23 cu. ft. interior, same 3/8 HP R-290 system, same tower arrangement — so the choice comes down to whether the sides of the box will ever be seen.
How do three kegs fit behind only two doors?
The BDD69-3B-HC is a single 69-3/8" wide compartment with two doors across the front, not three separate sections. The kegs sit side by side in one continuous 23 cu. ft. space, so door count and keg count do not have to match. In practice you roll a barrel in through whichever door is closest and slide it along the stainless steel floor.
Does this draft beer cooler have to be defrosted by hand?
No. Defrost is automatic on the BDD69-3B-HC, and the epoxy coated evaporator is built to resist corrosion in the humid air a keg box lives in. An air guard on the rear wall keeps circulation even across the bank so ice does not build up unevenly around the coil, which is the usual cause of a manual defrost on a draft cooler.
What electrical service and cord does the BDD69-3B-HC need?
A standard 115 V / 60 Hz single-phase receptacle. The 3/8 HP compressor draws 3.5 amps, so no dedicated high-amperage circuit is required, and the unit ships with a 9.8 ft (3 m) flexible three-wire cord and a molded NEMA 5-15P plug. That cord length usually reaches an outlet at either end of a 69" bar run without an extension.
Can the cabinet hold bottles or cans instead of kegs?
Yes. Each section comes with two adjustable shelves, and Blue Air specifies enough interior height to stack three tall boy cans, so the cooler doubles as bulk bottle and can storage when a keg comes out. The doors lock as standard, which is what you want if the box is holding packaged inventory overnight on a public-facing bar.
| Brand | Blue Air Commercial Refrigeration |
-
Price Match Request
Find better pricing? Just send it to us and ask for a quote! -
Financing Available, Flexible payment plans to fit your budget. Click here to explore your options
-
Guaranteed Safe Checkout
![[Price Match Guarantee] Price Match Guarantee](/web/image/dr.website.content/5/image/%5BPrice%20Match%20Guarantee%5D%20Price%20Match%20Guarantee?unique=3dc2115){kind=small}
| SKU | BDD69-3B-HC |
| Brand | Blue Air Commercial Refrigeration |
| Weight | 302.00 lbs |
| Dimensions (HxWxD) | 37.00 x 69.13 x 27.13 inches |
| Height | 37.00 |
| Width | 69.13 |
| Depth | 27.13 |
| Width | 60" - 72" |
| Column Qty | 2 columns / towers |
| Keg Capacity | 3 - 4 kegs |
| Top Style | flat top |
| Exterior Finish | black / stainless exterior |
| Faucet Qty | 1 & 2 faucets per column |
| Barrel Style | 1/2 barrel (full keg) |
|
